Silver 2U rack server front with 26 drive bays and bezel removed

DELL

DELL PowerEdge R740xd2 26-Bay 3.5" 2U Server 2x Xeon Gold 6230 2.1GHz 20C 16GB DDR4 H730P iDRAC9 2x 1100W

SKU CH-776W-47PB1

2U rack server with dual 20-core Xeon Gold 6230 CPUs, 16GB DDR4, PERC H730P controller and 26 hot-swap 3.5" drive bays

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.9GHz Turbo)
  • CPU SocketLGA 3647
  • Dual 20-core Xeon Gold 6230 CPUs deliver 40 threads at 2.1 GHz base
  • 26 front 3.5-inch bays provide massive storage density in 2U
  • PERC H730P 2 GB cache enables RAID 0/1/5/6/10/50/60
  • Dual 1100 W platinum PSUs ensure redundant hot-swap power
  • iDRAC 9 Enterprise gives full remote management with virtual console

2U Server with 26-Bay 3.5" Storage

The Dell PowerEdge R740xd2 is a 2U rack server built for data-intensive workloads that demand high storage density. Two Intel Xeon Gold 6230 processors deliver 20 cores each at 2.1 GHz with 3.9 GHz turbo for multi-threaded performance. The platform suits software-defined storage, backup repositories and large-scale archives.

PERC H730P Controller and 25Gb Networking

The bundled PERC H730P mini controller provides 2 GB cache and supports RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through for 26 drive trays. A Broadcom 57414 dual-port 10/25Gb SFP28 OCP 2.0 mezzanine card adds high-speed connectivity alongside the integrated dual-port 1GbE LOM. iDRAC 9 Enterprise enables full remote management.

DDR4 Memory Limit and PCIe Constraints

Installed memory is 16 GB DDR4-2666 ECC registered across two modules with 16 total slots supporting up to 1 TB capacity. The LGA 3647 socket platform reaches its maximum with two processors already installed. Expansion depends on available PCIe slots not detailed here, and front bezel with ready rails are not included.

Points forts

  • Dual 20-core Xeon Gold 6230 CPUs deliver 40 threads at 2.1 GHz base
  • 26 front 3.5-inch bays provide massive storage density in 2U
  • PERC H730P 2 GB cache enables RAID 0/1/5/6/10/50/60
  • Dual 1100 W platinum PSUs ensure redundant hot-swap power
  • iDRAC 9 Enterprise gives full remote management with virtual console

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelR740xd2
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.9GHz Turbo)
CPU SocketLGA 3647
Number of CPU Cores20 Core-Processors
CPU FeaturesGold 6230
# of Processors Installed2
MAX Processors2
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity1TB
Number of Memory Slots16
Hard Drive (Installed)None
Storage ControllerDell Perc H730P 2GB Controller
HDD Interface0
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet Controller1x Integrated Dual Port 1GbE LOM and 1x Dell EMC Broadcom 57414 Dual Port 10/25Gb SFP28 OCP 2.0 Mezzanine Card
Remote ManagementiDRAC9 Enterprise
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo
Features0

Questions sur cet article

What is the maximum DDR4 memory capacity this R740xd2 can take when I need to expand beyond the installed 16 GB?

The system supports up to 1 TB of DDR4 ECC registered memory across its 16 DIMM slots.

Which component will hit its limit first when the dual Xeon Gold 6230 processors run sustained heavy workloads?

The 1100 W platinum power supplies set the overall power envelope, capping sustained CPU turbo and total system draw before thermal limits are reached.

How much heat and noise should I expect from the redundant 1100 W supplies and 26 drive bays during continuous operation?

Dual platinum supplies run efficiently, but 26 spinning 3.5" drives plus two 20-core CPUs generate significant heat; the 2U chassis relies on high-speed fans that produce noticeable datacentre-level noise.
