Silver 2U rack server with sixteen 2.5-inch drive bays and front bezel

DELL

DELL PowerEdge R760 2U 16-bay 2x Xeon Gold 6430 3.4GHz 512GB DDR5 H965i 4x 1.92TB SATA 5720 iDRAC9 2x 1400W

SKU CH-WKJD-NK9T8

Two-socket 2U rack server with sixteen 2.5-inch bays, dual Xeon Gold 6430 32-core processors, 512 GB DDR5-4800 ECC memory, H965i RAID controller, four 1.92 TB SATA SSDs, quad-port 1 GbE OCP 3.0 NIC.

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.4GHz Turbo)
  • CPU SocketLGA 4677
  • Dual Xeon Gold 6430 CPUs deliver 64 cores at 3.4 GHz turbo
  • 512 GB DDR5-4800 ECC memory across 16 modules for high-capacity workloads
  • H965i RAID controller with 8 GB NV cache supports RAID 0 1 5 6 10 50 60
  • Four 1.92 TB SATA SSDs provide enterprise flash storage in 2.5 inch bays
  • iDRAC9 Datacenter and quad-port 1 GbE OCP 3.0 enable remote management and networking

Server Platform

The Dell PowerEdge R760 is a 2U rack server built for virtualization, AI inference, database clusters and software-defined storage. Two Intel Xeon Gold 6430 processors provide 32 cores at 2.1 GHz base with 3.4 GHz turbo for compute-intensive workloads. 512 GB of DDR5-4800 ECC registered memory across 16 modules supports large memory footprints. Sixteen 2.5-inch hot-swap bays accept SAS, SATA and NVMe drives.

Thermals and Power

Dual 1400 W platinum hot-plug power supplies deliver redundant hot-swap power for continuous availability. The 2U chassis uses managed fan curves that balance airflow against acoustic output in typical data-centre racks. Power draw scales with CPU utilisation and drive count, while the platinum-rated units maintain high efficiency across the load range. iDRAC9 Datacenter provides remote thermal monitoring and power capping policies.

Sustained Load Behaviour

Under prolonged heavy utilisation the dual Xeon Gold 6430 CPUs maintain turbo frequencies within the platform thermal envelope. The PERC H965i controller with 8 GB NV cache sustains RAID 0, 1, 5, 6, 10, 50 and 60 performance for four 1.92 TB SATA SSDs and additional drives. PCIe Gen5 slots and OCP 3.0 networking keep I/O pipelines full during extended AI training or database transactions. iDRAC9 lifecycle automation handles firmware updates without downtime.

Points forts

  • Dual Xeon Gold 6430 CPUs deliver 64 cores at 3.4 GHz turbo
  • 512 GB DDR5-4800 ECC memory across 16 modules for high-capacity workloads
  • H965i RAID controller with 8 GB NV cache supports RAID 0 1 5 6 10 50 60
  • Four 1.92 TB SATA SSDs provide enterprise flash storage in 2.5 inch bays
  • iDRAC9 Datacenter and quad-port 1 GbE OCP 3.0 enable remote management and networking

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelR760
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.4GHz Turbo)
CPU SocketLGA 4677
Number of CPU Cores32 Core-Processors
CPU FeaturesGold 6430
# of Processors Installed2
MAX Processors2
Installed Memory Size512GB
Memory TypeDDR5
Max Memory Capacity8TB
Number of Memory Slots32
Hard Drive (Installed)None
Storage ControllerDell Perc H965i Controller
HDD InterfaceSATA
SSD (Installed)4 x 1.92TB SATA SSD
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerDell EMC Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
Remote ManagementiDRAC9 Datacenter
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo

Questions sur cet article

How do I install the H965i RAID controller and which step is commonly missed?

Seat the H965i card in a PCIe Gen5 slot, connect the 8 GB NV cache module, then cable the 16 front 2.5″ bays; the step often missed is enabling the controller in the BIOS before creating RAID 0, 1, 5, 6, 10, 50 or 60 volumes.

What maintenance will the 4 × 1.92 TB SATA SSDs and the H965i cache require later?

The SSDs are hot-swap SATA drives — replace any failed unit without downtime; the H965i’s 8 GB NV cache is a sealed module that only needs replacement if the controller reports a cache fault.

What is the first limit reached when both Xeon Gold 6430 CPUs run at 3.4 GHz turbo under sustained load?

The 2 × 1400 W platinum power supplies set the thermal and current ceiling; prolonged 3.4 GHz operation on all 32 cores per socket will hit the 1400 W per supply rating before memory or storage bandwidth saturates.
