Dell PowerEdge R760 2U rack server, silver chassis, sixteen 2.5-inch drive bays, front bezel, dual 1400W power supplies

DELL

DELL PowerEdge R760 2U 16 Bay 2x Xeon Gold 6430 768GB DDR5 H965i 2x 1400W

SKU CH-BDN1-BRWEG

Two-processor 2U rack server with 32 cores, 768 GB DDR5, H965i RAID controller and sixteen 2.5" bays

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.4GHz Turbo)
  • CPU SocketLGA 4677
  • Dual Xeon Gold 6430 CPUs provide 64 cores at 2.1 GHz base
  • 768 GB DDR5-4800 ECC memory across 24 modules for high capacity
  • PERC H965i RAID controller with 8 GB NV cache supports RAID 0/1/5/6/10/50/60
  • Sixteen 2.5" hot-swap bays plus four included drive trays for flexible storage
  • Dual 1400 W platinum PSUs and iDRAC9 Datacenter deliver redundant power and remote management

Server identity

The Dell PowerEdge R760 is a 2U rack server equipped with two Intel Xeon Gold 6430 processors running at 2.1GHz with a 3.4GHz turbo frequency. Each CPU provides 32 cores, giving a total of 64 cores across the dual-socket platform. The system includes 768GB of DDR5-4800 ECC registered memory populated across 24 of the 32 available DIMM slots. It is designed for virtualisation, AI workloads, databases and software-defined storage environments.

Storage interface limits

Sixteen 2.5-inch hot-swap drive bays support SAS, SATA and NVMe devices, though only four drive trays are included. The Dell PERC H965i RAID controller with 8GB NV cache manages RAID 0, 1, 5, 6, 10, 50 and 60 across these drives. Network connectivity is provided by a Broadcom 5720 quad-port 1GbE OCP 3.0 adapter. PCIe Gen5 expansion slots are available for additional controllers or accelerators.

Memory capacity ceiling

The platform supports a maximum of 8TB of DDR5 ECC registered memory across 32 slots. Buyers who need more than 768GB must procure additional DDR5 modules separately. The server ships without any storage drives installed. Remote management is handled by iDRAC9 Datacenter with Lifecycle Controller. Dual 1400W platinum power supplies provide redundant hot-swap power. Ready rails and a front bezel are included for rack mounting.

Points forts

  • Dual Xeon Gold 6430 CPUs provide 64 cores at 2.1 GHz base
  • 768 GB DDR5-4800 ECC memory across 24 modules for high capacity
  • PERC H965i RAID controller with 8 GB NV cache supports RAID 0/1/5/6/10/50/60
  • Sixteen 2.5" hot-swap bays plus four included drive trays for flexible storage
  • Dual 1400 W platinum PSUs and iDRAC9 Datacenter deliver redundant power and remote management

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelR760
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.4GHz Turbo)
CPU SocketLGA 4677
Number of CPU Cores32 Core-Processors
CPU FeaturesGold 6430
# of Processors Installed2
MAX Processors2
Installed Memory Size768GB
Memory TypeDDR5
Max Memory Capacity8TB
Number of Memory Slots32
Hard Drive (Installed)None
Storage ControllerDell Perc H965i Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerDell EMC Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
Remote ManagementiDRAC9 Datacenter
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo

Questions sur cet article

Which drive bay count matches the 16-bay front panel on this R760?

The chassis provides sixteen 2.5-inch hot-swap bays, so the 16-bay version is the one that fits the front panel.

What does the 768 GB DDR5-4800 figure mean for actual memory bandwidth in this server?

Twenty-four 32 GB DDR5-4800 ECC RDIMMs fill 24 of 32 slots, delivering 4800 MT/s per module across all populated channels.

How does the OCP 3.0 slot limit network throughput with the installed 5720 card?

The Broadcom 5720 quad-port 1 GbE adapter runs at 1 Gbps per port, so the OCP 3.0 interface is not a bottleneck for this card.
