Silver 2U rack server with front bezel and sixteen 2.5 inch drive bays

DELL

DELL PowerEdge R760 2U rack server 2x Xeon Gold 6426Y 128GB DDR5 H965i 4x 2.5" trays 5720 iDRAC9 2x 1400W PSUs

SKU CH-00C0-QYJX0

2U rack server with dual 16-core Xeon Gold 6426Y CPUs, 128 GB DDR5, H965i RAID controller, quad-port 1 GbE OCP 3.0 card, iDRAC9 Datacenter, and redundant 1400 W power supplies

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.5GHz (4.1GHz Turbo)
  • CPU SocketLGA 4677
  • Dual 16-core Xeon Gold 6426Y CPUs reach 4.1GHz turbo for demanding workloads
  • 128GB DDR5-4800 ECC memory across 32 slots scales to 8TB capacity
  • PERC H965i RAID controller with 8GB NV cache supports RAID 0/1/5/6/10/50/60
  • Quad-port 1GbE OCP 3.0 adapter plus iDRAC9 Datacenter for remote management
  • Two 1400W platinum hot-swap PSUs deliver redundant power in 2U rack form

Dual-socket 2U server for enterprise workloads

The Dell PowerEdge R760 fits in a standard 2U rack space and ships with two Intel Xeon Gold 6426Y processors. Each CPU runs at 2.5 GHz with a 4.1 GHz turbo frequency and provides 16 cores. The system includes 128 GB of DDR5-4800 ECC registered memory across 32 slots, supporting up to 8 TB total capacity.

Hot-swap drive trays and OCP networking

The chassis holds sixteen 2.5-inch hot-swap bays; four Dell 16G drive trays are included. Storage is managed by a PERC H965i RAID controller with 8 GB NV cache supporting RAID 0, 1, 5, 6, 10, 50 and 60 for SAS, SATA and NVMe drives. A Broadcom 5720 quad-port 1 GbE OCP 3.0 network card provides four Ethernet links.

Redundant platinum power supplies and iDRAC9

Two 1400 W platinum-efficiency hot-swap power supplies deliver redundant power for continuous operation. Integrated iDRAC9 Datacenter enables remote management, monitoring and firmware updates without physical access. Ready Rails and a front bezel are included for straightforward rack installation.

Points forts

  • Dual 16-core Xeon Gold 6426Y CPUs reach 4.1GHz turbo for demanding workloads
  • 128GB DDR5-4800 ECC memory across 32 slots scales to 8TB capacity
  • PERC H965i RAID controller with 8GB NV cache supports RAID 0/1/5/6/10/50/60
  • Quad-port 1GbE OCP 3.0 adapter plus iDRAC9 Datacenter for remote management
  • Two 1400W platinum hot-swap PSUs deliver redundant power in 2U rack form

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelR760
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.5GHz (4.1GHz Turbo)
CPU SocketLGA 4677
Number of CPU Cores16 Core-Processors
CPU FeaturesGold 6426Y
# of Processors Installed2
MAX Processors2
Installed Memory Size128GB
Memory TypeDDR5
Max Memory Capacity8TB
Number of Memory Slots32
Hard Drive (Installed)None
Storage ControllerDell Perc H965i Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerDell EMC Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
Remote ManagementiDRAC9 Datacenter
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo

Questions sur cet article

What RAID modes does the PERC H965i controller support?

The PERC H965i supports RAID 0, 1, 5, 6, 10, 50, and 60 with its 8 GB NV cache.

How many 2.5-inch drive bays does the R760 chassis provide?

The 2U chassis includes sixteen hot-swap bays for SAS, SATA, or NVMe drives.

How do I access the iDRAC9 Datacenter interface for the first time?

Connect the dedicated management port, then browse to the default IP shown on the front LCD panel.
