DELL PowerEdge T430 16SFF Xeon E5-2683 v4 2.1GHz 192GB DDR4 No Drive Rack Server
A 16-bay 2.5-inch rack server with a 2.1 GHz Xeon E5-2683 v4, 192 GB DDR4 and a PERC H730 SAS controller
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.1GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size192GB
- 16 SFF bays for dense local storage
- Xeon E5-2683 v4 16-core CPU handles heavy workloads
- 192 GB DDR4 ECC memory supports large datasets
- PERC H730 SAS controller delivers hardware RAID
- iDRAC8 Express enables remote server management
PowerEdge T430 16SFF Rack Server
The Dell PowerEdge T430 is a 2U rack server delivered new with a single Intel Xeon E5-2683 v4 processor running at 2.1GHz and 192GB of DDR4 ECC registered memory. It uses a PERC H730 SAS controller that supports up to sixteen 2.5-inch SATA drives, though no drives are installed in this configuration. Remote management is provided by iDRAC8 Express and dual 1100W power supplies are fitted.
Suited For Virtualisation And Database Workloads
This server suits environments that need high core counts and large memory capacity for virtualisation, database or compute tasks within a standard rack footprint. The sixteen-bay chassis allows dense local storage using SATA media. Buyers who need a second processor installed, GPU acceleration, or storage interfaces beyond SATA and SAS should evaluate other platforms because this unit ships with one CPU and integrated graphics only.
Single Processor Limits Maximum Memory To 192GB
The critical specification is the single Xeon E5-2683 v4 processor, which provides sixteen cores and 40MB cache but restricts the maximum addressable memory to 384GB across both CPU sockets. With only one socket populated the installed 192GB represents the practical ceiling unless a second compatible processor is added. Buyers planning workloads that require more than 192GB of RAM must procure a second processor to reach the platform limit.
Points forts
- 16 SFF bays for dense local storage
- Xeon E5-2683 v4 16-core CPU handles heavy workloads
- 192 GB DDR4 ECC memory supports large datasets
- PERC H730 SAS controller delivers hardware RAID
- iDRAC8 Express enables remote server management
Caractéristiques
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.1GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 192GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 384GB |
| Hard Drive (Installed) | 3,84 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Express License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
Will the 36 x 24 x 10 in chassis fit in a standard 19-inch rack?
The T430 is a rack-mount server measuring 36 inches deep, 24 inches wide and 10 inches high; it occupies a standard 19-inch rack footprint but verify cabinet depth before ordering.
How do I install the PERC H730 RAID controller and what step is often missed?
The PERC H730 ships pre-installed in the dedicated internal slot; the step people miss is importing the foreign configuration when moving drives from another controller.
When will the 192 GB DDR4 ECC memory need replacement or expansion?
DDR4 ECC modules typically run for years; plan expansion when workloads exceed 192 GB — the system supports up to 384 GB across the remaining DIMM slots.
