Silver 5U rack server chassis with front drive bays and bezel removed

DELL

DELL PowerEdge T440 5U rack server 2x Xeon Gold 5120 2.2GHz 14-core 16GB DDR4 4x 960GB SSD HBA330 2x 750W PSU

SKU CH-993V-XVZYR

5U rack server with dual 14-core Xeon Gold 5120 CPUs at 2.2GHz, 16GB DDR4, HBA330 controller and four 960GB SSDs

  • TypeRack
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.2GHz (3.2GHz Turbo)
  • CPU SocketLGA 3647
  • Dual 14-core Xeon Gold 5120 CPUs at 2.2 GHz base with 3.2 GHz turbo
  • 16 GB DDR4-2400 ECC registered memory in two modules with 16 slots for expansion
  • PERC HBA330 12 Gb/s SAS/SATA controller managing four 960 GB enterprise SSDs
  • Dual 750 W platinum-efficiency hot-swap power supplies for full redundancy
  • iDRAC 9 Express remote management plus dual-port gigabit Ethernet built in

Dual Xeon Gold 5120 5U server

The Dell PowerEdge T440 is a 5U rack server fitted with two Intel Xeon Gold 5120 processors, each running at 2.2 GHz with a 3.2 GHz turbo across 14 cores. It ships with 16 GB of DDR4-2400 ECC registered memory across two modules and a PERC HBA330 controller driving four 960 GB SATA SSDs. This configuration targets organisations that need a ready-to-deploy platform for virtualisation, database hosting or file storage.

Upgrading from single-socket or older generation

Moving from a single-processor tower or an earlier 12-core platform adds a second 14-core CPU and doubles the memory channels, which helps when consolidating multiple VMs or running memory-bound databases. The jump is worthwhile when workloads exceed the thread count or memory bandwidth of a single socket and the 16-bay chassis provides room for future storage growth.

Sustained load behaviour with dual 750 W PSUs

Redundant 750 W platinum power supplies and hot-swap drive bays keep the system running during component replacement or a single PSU failure. The HBA330 controller manages steady I/O to the SATA SSDs without a RAID cache, so write latency stays consistent during long backup windows or SDS rebuilds. iDRAC 9 Express allows remote monitoring and power cycling without physical access.

Points forts

  • Dual 14-core Xeon Gold 5120 CPUs at 2.2 GHz base with 3.2 GHz turbo
  • 16 GB DDR4-2400 ECC registered memory in two modules with 16 slots for expansion
  • PERC HBA330 12 Gb/s SAS/SATA controller managing four 960 GB enterprise SSDs
  • Dual 750 W platinum-efficiency hot-swap power supplies for full redundancy
  • iDRAC 9 Express remote management plus dual-port gigabit Ethernet built in

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelT440
TypeRack
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.2GHz (3.2GHz Turbo)
CPU SocketLGA 3647
Number of CPU Cores14 Core-Processors
CPU FeaturesGold 5120
# of Processors Installed2
MAX Processors2
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity1TB
Number of Memory Slots16
Hard Drive (Installed)None
Storage ControllerDell Perc HBA330 Controller
HDD InterfaceSATA
SSD (Installed)4 x 960GB SATA SSD
Raid LevelNone
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
Remote ManagementiDRAC9 Express
LAN Ports2 x Ports
Management PortRJ 45
Operating SystemNo

Questions sur cet article

What rack space and rails does the 5U T440 require for mounting?

The server occupies 5U of rack height; the front bezel and ready rails are not included, so you must supply compatible rack rails and ensure 5U of continuous vertical clearance in a standard rack cabinet.

How are the dual Xeon Gold 5120 processors and DDR4 memory installed, and what step is often missed?

Both LGA 3647 sockets are already populated with the two 14-core 2.2 GHz CPUs; the 16 GB ships as two 8 GB DDR4-2400 ECC RDIMMs in two of the sixteen slots, and the step often missed is populating remaining slots in the correct per-channel sequence for optimal performance.

Which components in this T440 will need replacement or maintenance over time?

The two hot-swap 750 W platinum power supplies, the four 960 GB SATA SSDs, the system cooling fans, and the CMOS battery are the field-replaceable items that typically require attention during the server's lifespan.
