Silver 5U rack chassis with sixteen 2.5-inch drive bays and dual power supplies

DELL

DELL PowerEdge T440 5U rack server 2x Xeon Gold 5120 2.2GHz 14C 128GB DDR4 4x 960GB SSD HBA330 2x 750W

SKU CH-QBCE-TXKAC

A 5U rack server with dual 14-core Xeon Gold 5120 processors at 2.2 GHz, 128 GB DDR4 ECC memory, a PERC HBA330 controller and four 960 GB SATA SSDs in a 16-bay chassis

  • TypeRack
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.2GHz (3.2GHz Turbo)
  • CPU SocketLGA 3647
  • Dual Xeon Gold 5120 CPUs deliver 28 total cores for heavy workloads
  • 128GB DDR4 ECC memory supports large virtualisation environments
  • Four 960GB SATA SSDs provide fast redundant storage capacity
  • HBA330 controller enables flexible SAS and SATA drive configurations
  • Redundant 750W platinum power supplies maintain uptime during failures

Built for virtualization and database workloads

This 5U rack server ships with two Intel Xeon Gold 5120 processors at 2.2 GHz with 3.2 GHz turbo across 14 cores each. 128 GB of DDR4-2400 ECC registered memory fills four of sixteen slots. A Dell PERC HBA330 controller manages four 960 GB SATA SSDs in 2.5 inch hot-swap bays. Dual 750 W platinum power supplies provide redundancy.

Upgrade from single-socket

Moving from a single-processor platform doubles compute threads and memory channels for heavier consolidation ratios. The sixteen 2.5 inch bays and HBA330 controller replace direct-attached SATA backplanes that limit drive count and RAID flexibility. The jump is worth it when workloads need more simultaneous VMs, larger in-memory databases, or room to grow storage without a second chassis.

Verify rack depth and rail kit before ordering

This unit is a tower chassis that requires the optional rack conversion kit for cabinet mounting; ready rails and front bezel are not included. Confirm the HBA330 meets your RAID level requirements because it operates in HBA mode without hardware RAID. Ensure your network infrastructure uses the integrated dual-port gigabit adapter or plan for additional NICs. Power cords for the 750 W supplies should match your PDU connectors.

Points forts

  • Dual Xeon Gold 5120 CPUs deliver 28 total cores for heavy workloads
  • 128GB DDR4 ECC memory supports large virtualisation environments
  • Four 960GB SATA SSDs provide fast redundant storage capacity
  • HBA330 controller enables flexible SAS and SATA drive configurations
  • Redundant 750W platinum power supplies maintain uptime during failures

Caractéristiques

BrandDELL
SeriesPowerEdge
ModelT440
TypeRack
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.2GHz (3.2GHz Turbo)
CPU SocketLGA 3647
Number of CPU Cores14 Core-Processors
CPU FeaturesGold 5120
# of Processors Installed2
MAX Processors2
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity1TB
Number of Memory Slots16
Hard Drive (Installed)None
Storage ControllerDell Perc HBA330 Controller
HDD InterfaceSATA
SSD (Installed)4 x 960GB SATA SSD
Raid LevelNone
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
Remote ManagementiDRAC9 Express
LAN Ports2 x Ports
Management PortRJ 45
Operating SystemNo

Questions sur cet article

What rack height and drive-bay count does the T440 require?

The server is a 5U unit with sixteen 2.5-inch hot-swap bays, so the rack must provide 5U of vertical space and support 2.5-inch drive carriers.

How are the two Xeon Gold 5120 processors installed, and what step is often missed?

Both LGA 3647 sockets are populated; the common oversight is forgetting to apply the correct torque sequence on the CPU retention brackets before closing the heatsink latches.

When will the 960GB SSDs and DDR4 memory need replacement?

The four 960GB SATA SSDs should be monitored for wear-level indicators and replaced once their endurance rating is reached, while the 128GB DDR4-2400 ECC modules only need swapping if a DIMM fails or capacity must exceed 1TB.
