Black 92mm fan on aluminium fin stack with four heat pipes, horizontal mount, 110mm tall

Dynatron

Dynatron R17 92mm 2 Ball CPU Cooler LGA 2011/2066 160W TDP

SKU CH-MDZF-7RVDG MPN R17

92 mm dual-ball-bearing fan cools LGA 2011/2066 CPUs up to 160 W TDP in 3U servers and tower workstations

  • ColorBlack
  • TypeFan & Heatsinks
  • Fan Size92mm
  • CPU Socket CompatibilityIntel LGA 2066 / 2011 (Square Type, 80 x 80mm mounting pitch
  • Bearing Type2 Ball
  • RPMAt Duty Cycle 20%: 1000 RPM, At Duty Cycle 50%: 1800 RPM, At
  • Cools up to 160 W TDP for overclocked Intel LGA 2011/2066 CPUs
  • Four heat pipes with H.C.C. technology move heat efficiently from the processor
  • 92 mm dual-ball-bearing fan runs at 1000 RPM on low duty cycle
  • Quiet 17.0 dBA at 20 % duty cycle for low-noise environments
  • Compact 110 mm height fits 3U and taller server, workstation or tower chassis

Socket 2011/2066 160W Cooler

The Dynatron R17 is a 92mm air cooler rated for Intel LGA 2011 and LGA 2066 processors with a 160W TDP. It fits 3U and taller server chassis as well as workstation and tower desktop builds. The unit uses a 4-pin PWM connector for automatic speed control.

Sustained Load Behaviour

At 20% duty the fan spins at 1000 RPM delivering 17.34 CFM at 17.0 dBA. At 50% duty it reaches 1800 RPM with 31.21 CFM at 24.78 dBA. At full 100% duty it runs at 2500 RPM producing 43.36 CFM at 31.92 dBA, maintaining airflow under continuous thermal load.

Build And Mounting

The heatsink combines aluminium fins with four heat pipes using H.C.C. technology and stands 110mm tall. A horizontal 92x25mm two-ball-bearing fan mounts on top. The square 80x80mm mounting pitch matches the LGA 2011/2066 pattern. Total weight is 530g.

Points forts

  • Cools up to 160 W TDP for overclocked Intel LGA 2011/2066 CPUs
  • Four heat pipes with H.C.C. technology move heat efficiently from the processor
  • 92 mm dual-ball-bearing fan runs at 1000 RPM on low duty cycle
  • Quiet 17.0 dBA at 20 % duty cycle for low-noise environments
  • Compact 110 mm height fits 3U and taller server, workstation or tower chassis

Caractéristiques

BrandDynatron
ModelR17
ColorBlack
TypeFan & Heatsinks
Fan Size92mm
CPU Socket CompatibilityIntel LGA 2066 / 2011 (Square Type, 80 x 80mm mounting pitch)
Bearing Type2 Ball
RPMAt Duty Cycle 20%: 1000 RPM, At Duty Cycle 50%: 1800 RPM, At Duty Cycle 100%: 2500 RPM
Air FlowAt Duty Cycle 20%: 17.34 CFM, At Duty Cycle 50%: 31.21 CFM, At Duty Cycle 100%: 43.36 CFM
Noise LevelAt Duty Cycle 20%: 17.0 dBA, At Duty Cycle 50%: 24.78 dBA, At Duty Cycle 100%: 31.92 dBA
Power Connector4 Pin
Heatsink MaterialAluminum Fins, 4x Heat Pipes with H.C.C. Technology
Fan Mounting Types to HeatsinkHorizontal
Max CPU Cooler Height110 mm
Fan Dimensions92 x 25 mm
Weight530g
FeaturesIntel Sandy Bridge Romley-EP/EX Processors up to TDP 160 Watts overclocking for socket 2011 3U&Up Server, Workstation, Tower Desktop Solution
Solution: 3U&Up, Workstation & Tower Desktop Solution
Rated Voltage: 12 V
Power:
At Duty Cycle 20%: 0.96 W
At Duty Cycle 50%: 1.44 W
At Duty Cycle 100%: 3.0 W
Air Pressure:
At Duty Cycle 20%: 0.48 mm-H2O
At Duty Cycle 50%: 1.55 mm-H2O
At Duty Cycle 100%: 3.0 mm-H2O
*Note:
Support CPU Power up to 160 Watts
Pre-print thermal compound Shin-Etsu G751
RoHS Compliance
Backplate is not included
Poids d’expédition0.66 kg
Dimensions du colis142 × 135 × 130 mm

Questions sur cet article

How loud is the 92 mm fan when the cooler runs at full duty cycle all day?

At 100 % duty cycle the fan spins at 2500 RPM and produces 31.92 dBA while moving 43.36 CFM.

What motherboard mounting pattern must I already have for this cooler to fit?

The cooler uses the square-type LGA 2011/2066 pattern with an 80 x 80 mm pitch and requires a standard 4-pin PWM header.

Will the 110 mm tall heatsink clear the memory modules on my existing LGA 2011 workstation board?

The 110 mm height is designed for 3U-and-up server chassis; on a tower board you must verify DIMM clearance against that dimension.
