Green rectangular motherboard with silver CPU socket, black memory slots and silver expansion slots

GIGABYTE

GIGABYTE GA-P61-DS3-B3 Intel motherboard

SKU CH-0AAG-XEEH8

LGA 1155 Intel H61 board with dual DDR3 slots up to 16 GB, Realtek ALC889 108 dB audio, RTL8111E gigabit LAN, one PCIe 2.0 x16 and two PCIe x1 slots

  • CPU Socket TypeLGA 1155
  • Supports LGA 1155 2nd Gen Intel Core processors
  • Intel H61 Express Chipset with B3 stepping support
  • Four-phase CPU power design with all solid capacitors
  • Realtek ALC889 108dB audio for 7.1-channel playback
  • DualBIOS protection enables 3TB+ HDD boot capability

Socket LGA 1155 Platform Board

The GIGABYTE GA-P61-DS3-B3 is an Intel H61 Express motherboard built for LGA 1155 processors. It accepts second generation Core i7, i5 and i3 CPUs as well as Pentium and Celeron models in the same package. The board provides two 1.5V DDR3 DIMM slots supporting up to 16 GB of dual-channel memory at 1333, 1066 or 800 MHz.

Replaces Older LGA 1155 Boards With B3 Stepping

This model upgrades earlier 6 series boards by using the newer B3 stepping chipset and a four-phase CPU power design. The all solid capacitor layout and DualBIOS protection add reliability for long-term use. The jump is worth it when a system needs 3 TB plus hard drive boot support or improved USB power delivery for connected devices.

Standard ATX Installation With Legacy Slots

The board fits a standard ATX chassis and uses a single PCI Express x16 slot running at x16 plus two x1 slots all conforming to the 2.0 standard. Three conventional PCI slots remain for older add-in cards. Builders should verify CPU cooler clearance against the solid capacitor array and confirm memory modules are on the qualified vendor list to avoid boot issues.

Points forts

  • Supports LGA 1155 2nd Gen Intel Core processors
  • Intel H61 Express Chipset with B3 stepping support
  • Four-phase CPU power design with all solid capacitors
  • Realtek ALC889 108dB audio for 7.1-channel playback
  • DualBIOS protection enables 3TB+ HDD boot capability

Caractéristiques

CPU Socket TypeLGA 1155

Questions sur cet article

What are the DDR3 memory voltage and capacity limits for this board?

The board has two 1.5V DDR3 DIMM sockets that support up to 16 GB of system memory in dual-channel mode.

Which expansion slots are available and what PCIe standard do they follow?

It provides one PCI Express x16 slot running at x16, two PCI Express x1 slots, and three PCI slots, all conforming to the PCI Express 2.0 standard.

How is audio upgraded from 5.1 to 7.1 channel output on this motherboard?

To enable 7.1-channel audio you must install an HD front panel audio module and activate the multi-channel feature through the Realtek ALC889 audio driver.
