Black fanless mini PC with dual HDMI ports and two LAN sockets

GigaIPC

GigaIPC 6BQB6412AMR-SI-3WC1 AI edge system

SKU CH-CAZ6-8239J MPN 6BQB6412AMR-SI-3WC1

Fanless industrial mini PC with Intel Celeron J6412 quad-core processor, dual HDMI up to 4096×2160 at 60 Hz, dual Gigabit LAN, four USB 3.2 Gen 2 ports, one COM port.

  • ColorBlack
  • CPU TypeIntel Celeron J6412
  • Memory installedNo Memory
  • Memory slot1 x 260Pin SO-DIMM
  • Memory Type SupportedDDR4 3200
  • Max Memory Supported32GB
  • Fanless design enables silent operation in noise-sensitive environments
  • Intel Celeron J6412 quad-core processor handles edge AI workloads efficiently
  • Dual HDMI outputs support 4096x2160 resolution at 60Hz for dual 4K displays
  • Four USB 3.2 Gen2 ports plus COM RS-232 connect diverse industrial peripherals
  • Dual Intel I211AT GbE LAN ports provide reliable wired network redundancy

Compact fanless AI edge system

The GigaIPC 6BQB6412AMR-SI-3WC1 is an industrial mini PC built around the Intel Celeron J6412 quad-core processor. Its fanless chassis measures 4.65 by 4.31 by 1.75 inches, making it suitable for IoT gateway, digital signage or control system deployments where silent operation and a small footprint are required.

Build integration and expansion

The unit provides one 260-pin SO-DIMM slot accepting DDR4 3200 memory up to 32 GB, plus a 2280 M.2 M-key slot supporting PCIe x2 and SATA storage. A 2230 M.2 E-key slot is available for wireless modules. Dual Intel I211AT gigabit LAN ports, four USB 3.2 Gen 2 ports and a COM RS-232 header cover typical industrial connectivity.

Capacity and headroom

Integrated Intel UHD Graphics drives two HDMI outputs at up to 4096 by 2160 at 60 Hz for dual-display installations. The single memory channel and PCIe x2 storage lane limit throughput for memory-intensive or high-bandwidth workloads, so applications needing greater parallelism or faster storage queues will exceed the platform’s design envelope.

Points forts

  • Fanless design enables silent operation in noise-sensitive environments
  • Intel Celeron J6412 quad-core processor handles edge AI workloads efficiently
  • Dual HDMI outputs support 4096x2160 resolution at 60Hz for dual 4K displays
  • Four USB 3.2 Gen2 ports plus COM RS-232 connect diverse industrial peripherals
  • Dual Intel I211AT GbE LAN ports provide reliable wired network redundancy

Caractéristiques

BrandGIGAIPC
ModelQBiX-EHLA6412-A1
ColorBlack
CPU TypeIntel Celeron J6412
Memory installedNo Memory
Memory slot1 x 260Pin SO-DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported32GB
Other1 x 2230 M.2 E-Key (WiFi/BT)
Storage InstalledNo Hard Drive
M.2 Slot1 x 2280 M.2 M-Key (PCIe x2, SATA 6Gb/s)
Integrated GraphicsIntel UHD Graphics
LANIntel I211AT
Max LAN SpeedDual 1Gbps
Front USB2 x USB 3.2 Gen 2x1
Other Front Ports1 x COM Port (RS-232)
1 x Combo Audio Jack (Headphone & Headset)
1 x Power button with LED
HDMI2 x HDMI
Rear USB2 x USB 3.2 Gen 2x1
RJ452 x RJ45 LAN Ports
Other Rear Ports1 x Screw Type DC Jack
Power Supply+12V~19VDC (Adapter 19V/65W)
Dimensions4.65" x 4.31" x 1.75"
PackagingPSU ADP 19V 65W 100-240VAC x 1 (P/N: 25EP1-100651-A3S)
VESA Bracket x 1 (P/N: 25HB1-TPL021-S8R)
VESA Screws x 1 (P/N: 25KSD-000001-S4R)
Poids d’expédition1.54 kg
Dimensions du colis260 × 197 × 133 mm

Questions sur cet article

What memory do I need to add before this system will boot?

Install one DDR4 3200 SO-DIMM up to 32 GB in the single 260-pin slot; the unit ships with no memory installed.

Which M.2 SSD form factor and interface are supported for primary storage?

The 2280 M-key slot accepts PCIe x2 or SATA drives; no drive is included.

Can I mount two independent displays at 4K resolution?

Yes, the dual HDMI ports each support up to 4096x2160 at 60 Hz.
