Silver 1U rack server front panel with eight 2.5 inch drive bays

HP

HP ProLiant DL160 Gen9 1U Rack Server E5-2650 v3 10C 2.3GHz 32GB DDR4 H240

SKU CH-FPJV-DJQBR

1U rack server with a 10-core Xeon at 2.3 GHz, 32 GB DDR4 and an H240 RAID controller supporting eight 2.5-inch drives

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 32GB

HDD None

  • 10-core Xeon E5-2650 v3 at 2.3 GHz for multi-threaded workloads
  • 32 GB DDR4 ECC memory across 16 DIMM slots
  • Smart HBA H240 supports 12 Gb SAS and 6 Gb SATA RAID 0/1/5
  • Redundant hot-swap 550 W power supply for uptime
  • 1U rack chassis with eight 2.5-inch drive bays

ProLiant DL160 Gen9 1U Server

The HP ProLiant DL160 Gen9 is a 1U rack server built around a single Intel Xeon E5-2650 v3 ten-core processor running at 2.3 GHz. It ships with 32 GB of DDR4 ECC registered memory across 16 DIMM slots and includes an HP Smart HBA H240 storage controller supporting RAID 0, 1 and 5. Redundant hot-swap 550 W power supplies are fitted and no operating system is included.

Suits dense compute and storage workloads

This configuration suits environments that need up to eight 2.5-inch SFF drive bays in a 1U form factor with hardware RAID and dual-processor capability. Buyers who require more than eight internal drive bays, a dedicated graphics processor, or an operating system pre-installed should look elsewhere.

Single Xeon E5-2650 v3 limits peak threads

The installed processor provides ten cores and twenty threads with hyper-threading; a second socket is available to double that count. If the workload demands more than twenty threads from a single CPU, the current single-processor layout will not meet that need.

Points forts

  • 10-core Xeon E5-2650 v3 at 2.3 GHz for multi-threaded workloads
  • 32 GB DDR4 ECC memory across 16 DIMM slots
  • Smart HBA H240 supports 12 Gb SAS and 6 Gb SATA RAID 0/1/5
  • Redundant hot-swap 550 W power supply for uptime
  • 1U rack chassis with eight 2.5-inch drive bays

Caractéristiques

BrandHP
SeriesProLiant
ModelProliant DL160 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity32GB
Memory Features16 DIMM slots, 8 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots16
Storage ControllerHP Smart HBA H240 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports2 x Ports
Expansion SlotsCPU1 PCIe Riser 1: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Low Profile slot. Optional kit available to install Flexible LOM in slot 1. CPU 2 Riser (Optional): PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How much power does the 550W redundant supply draw when the Xeon E5-2650 v3 runs at full load all day?

The server ships with a 550W hot-swap power supply; actual draw depends on workload but the unit is rated for 550W maximum.

Which drives and caddies must I supply to populate the eight 2.5-inch bays?

You need up to eight 2.5-inch SAS or SATA drives plus the included drive trays and screws; no drives are installed.

Will my existing DDR4 ECC registered modules work in the sixteen DIMM slots alongside the installed 32GB?

Yes, the sixteen slots accept 4GB, 8GB, 16GB, 32GB or 64GB DDR4 ECC registered DIMMs up to 2400MT/s, speed limited by the processor.
