HPE
HPE P83293-005 ProLiant DL380 Gen11 4410Y 2.0GHz 12-Core 64GB DDR5 2x960GB SATA SSD 2x800W Rack Server
A 1U rack server with a 12-core Xeon 4410Y at 2.0 GHz, 64 GB DDR5, dual 960 GB SATA SSDs and redundant 800 W supplies
- WorkloadGeneral Purpose Server
- TypeRack
- Rack Height1U
- Hot-swap Fans4 x Standard Fan
- CPU TypeIntel Xeon Silver
- CPU Speed4410Y (2.00 GHz)
- 12-core Xeon 4410Y at 2.00 GHz powers multi-thread workloads
- 64 GB DDR5 Smart Memory at 4800 MT/s speeds data access
- 2 x 960 GB SATA read-intensive SSDs deliver fast boot and logs
- MR408i-o controller with 4 GB cache accelerates RAID performance
- Redundant 800 W Platinum hot-plug supplies keep uptime high
HPE ProLiant DL380 Gen11 12-Core Server
This 1U rack server ships with an Intel Xeon Silver 4410Y at 2.0 GHz, 12 cores and 30 MB L3 cache. It includes 64 GB of HPE DDR5 Smart Memory as 2x32 GB modules at 4800 MT/s. Two 960 GB SATA SSDs and a MR408i-o controller with 4 GB cache provide the boot and data layer. Dual 800 W hot-plug supplies deliver redundant power.
Suits general-purpose rack workloads needing 1U
Buyers who need more than one processor socket or more than 64 GB of memory should evaluate larger configurations. Workloads that demand 10 GbE or 25 GbE connectivity out of the box will require additional adapters. Environments limited to 3.5-inch drive bays cannot use the 8 SFF front bays.
Deciding spec: single 12-core Xeon Silver 4410Y
Only one CPU is installed, so the platform tops out at 12 cores and 64 GB unless a second processor kit is added later. If the target application scales beyond that core count or memory ceiling, a dual-socket model is the appropriate starting point.
Points forts
- 12-core Xeon 4410Y at 2.00 GHz powers multi-thread workloads
- 64 GB DDR5 Smart Memory at 4800 MT/s speeds data access
- 2 x 960 GB SATA read-intensive SSDs deliver fast boot and logs
- MR408i-o controller with 4 GB cache accelerates RAID performance
- Redundant 800 W Platinum hot-plug supplies keep uptime high
Caractéristiques
| Brand | HPE |
|---|---|
| Series | ProLiant DL380 G11 |
| Model | P83293-005 |
| Workload | General Purpose Server |
| Type | Rack |
| Rack Height | 1U |
| Hot-swap Fans | 4 x Standard Fan |
| CPU Type | Intel Xeon Silver |
| CPU Speed | 4410Y (2.00 GHz) |
| Number of CPU Cores | 12-Core Processor |
| Cache Memory | 30 MB L3 Cache |
| # of Processors Installed | 1 |
| Installed Memory Size | 64 GB (2x32 GB, 4800 MT/s) |
| Memory Type | HPE DDR5 Smart Memory |
| Storage Controller | HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller |
| SSD (Installed) | 2 x HPE 960GB SATA 6G Read Intensive SFF |
| Ethernet Controller | Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE |
| Expansion Slots | Up to 8 PCIe Gen5, and 2 OCP 3.0 |
| Power Characteristics | 2 x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit |
| Dimensions | 10.75" x 23.62" x 39.29" |
| Weight | 91.095 lbs. |
| Poids d’expédition | 18.14 kg |
| Dimensions du colis | 508 × 508 × 152 mm |
Questions sur cet article
What rack height and power connections does the 1U DL380 Gen11 need?
The server occupies 1U of rack space and ships with two hot-plug 800 W Flex Slot Platinum power supplies, so two compatible PDU outlets are required.
Will the BCM5719 1 GbE OCP 3.0 adapter work with my existing 1 Gb switches?
Yes, the Broadcom BCM5719 provides four 1 Gb BASE-T ports that negotiate automatically with standard 1 Gb Ethernet switches.
How do I confirm the MR408i-o controller sees both 960 GB SSDs after installation?
During POST or in the iLO interface, the MR408i-o storage controller will list both 960 GB SATA drives as logical volumes if they are detected correctly.
