HPE
HPE ProLiant DL360 Gen10 1U rack server P19180-B21 Xeon 6242 16-core 2.80 GHz 800W
1U rack server with 16-core Xeon 6242 at 2.80 GHz, 800 W hot-plug supply, dual 25 Gb SFP28 ports and HPE Smart Array P408i-a controller
- TypeBlade
- Rack Height1U
- CPU TypeIntel Xeon Scalable
- CPU Speed6242 (2.80 GHz)
- Number of CPU Cores16-Core Processor
- CPU Features150W TDP
- 16-core Xeon 6242 at 2.80 GHz powers dense workloads
- 1U rack form factor fits space-constrained data centres
- HPE Smart Array P408i-a with 2 GB cache accelerates storage I/O
- Dual 10/25 Gb SFP28 ports deliver high-speed networking
- 800 W Flex Slot Platinum hot-plug supply ensures efficient power
Dense 1U compute node
The HPE ProLiant DL360 Gen10 is a 1U rack server built around a single Intel Xeon 6242 processor with 16 cores at 2.80 GHz. It ships with an 800W Flex Slot Platinum hot-plug power supply and an HPE Smart Array P408i-a controller with 2 GB cache plus Smart Storage Battery. Two 10/25 Gb SFP28 ports and two PCIe 3.0 slots provide network and expansion connectivity in a 1.69" x 17.11" x 27.83" chassis weighing 42.4 lbs.
Virtualization and database clusters
This configuration suits teams deploying virtualization, database or high-performance computing workloads in space-constrained racks who want integrated management through HPE OneView and iLO 5. Buyers who need multiple processors installed from the factory or who require pre-populated memory and storage should look at a different build.
Scalable memory and storage headroom
The platform supports up to 3.0 TB of HPE DDR4 SmartMemory at 2933 MT/s and can accommodate 10 NVMe drives for high-speed storage tiers. With only 32 GB quoted in the supplier title and no drives installed, memory capacity and storage performance will run out quickly for large working sets unless additional modules and drives are added.
Points forts
- 16-core Xeon 6242 at 2.80 GHz powers dense workloads
- 1U rack form factor fits space-constrained data centres
- HPE Smart Array P408i-a with 2 GB cache accelerates storage I/O
- Dual 10/25 Gb SFP28 ports deliver high-speed networking
- 800 W Flex Slot Platinum hot-plug supply ensures efficient power
Caractéristiques
| Brand | HPE |
|---|---|
| Model | P19180-B21 |
| Type | Blade |
| Rack Height | 1U |
| CPU Type | Intel Xeon Scalable |
| CPU Speed | 6242 (2.80 GHz) |
| Number of CPU Cores | 16-Core Processor |
| CPU Features | 150W TDP |
| # of Processors Installed | 1 |
| Installed Memory Size | No |
| Memory Type | HPE DDR4 SmartMemory |
| Hard Drive (Installed) | None |
| Storage Controller | HPE Smart Array P408i-a/2 GB plus Smart Storage Battery |
| Ethernet Controller | HPE Ethernet 10/25 Gb 2-port 640FLR -SFP28 Adapter |
| LAN Ports | 2 x Ports |
| Expansion Slots | 2 PCIe 3.0 |
| Operating System | No |
| Power Characteristics | 1 HPE 800W Flex Slot Platinum hot-plug power supply |
| Dimensions | 1.69" x 17.11" x 27.83" |
| Weight | 42.4 |
| Poids d’expédition | 12.70 kg |
| Dimensions du colis | 762 × 508 × 127 mm |
Questions sur cet article
What memory type and speed must I already have to populate the DDR4 SmartMemory slots on this server?
You need HPE DDR4 SmartMemory modules rated for 2933 MT/s to match the supported memory specification.
Can the HPE Smart Array P408i-a controller manage my existing 12 Gb/s SAS drives alongside any new drives I add?
Yes, the P408i-a controller supports 12 Gb/s SAS connectivity, so it can manage your current SAS drives together with additional compatible drives.
How do I verify the 10/25 Gb Ethernet adapter is linked at the correct speed after installation?
Check the link LED on each SFP28 port and confirm the negotiated speed in the operating system or iLO 5 network settings.
