HPE
HPE ProLiant DL380 Gen9 12LFF rack server 1x Xeon E5-2690 v4 64GB DDR4
A 12-bay 3.5-inch rack server with one 14-core Xeon E5-2690 v4 at 2.6 GHz and 64 GB DDR4, ready for storage expansion
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.6GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size64GB
- 14-core Xeon E5-2690 v4 delivers strong multi-thread performance
- 64 GB DDR4 ECC memory supports demanding workloads
- 12 large-form-factor bays provide high storage capacity
- Dual 800 W hot-plug supplies ensure power redundancy
- HPE iLO Advanced enables remote server management
ProLiant DL380 Gen9 12LFF Server
The HPE ProLiant DL380 Gen9 is a 12-bay 3.5-inch rack server delivered with one Intel Xeon E5-2690 v4 processor running at 2.6GHz and 14 cores. It includes 64GB of DDR4 ECC registered memory and an HP Smart Array P440ar controller with SAS expander. The chassis supports up to two processors and a maximum of 3TB of memory.
IT teams needing dense 3.5-inch storage
This configuration suits IT teams that need twelve 3.5-inch drive bays for large-capacity SATA drives and a single-socket compute base. The installed P440ar controller manages RAID across the backplane. Buyers who require two processors from day one or more than 64GB of memory should evaluate other configurations. The unit ships without any drives installed.
Twelve 3.5-inch drive bays with P440ar RAID
The defining specification is the 12LFF chassis that holds twelve 3.5-inch SATA drives behind an HP Smart Array P440ar controller with SAS expander. This layout determines how many drives you can add and what RAID levels are supported. The server also provides dual 800W hot-plug power supplies and integrated 10GbE plus 1GbE networking.
Points forts
- 14-core Xeon E5-2690 v4 delivers strong multi-thread performance
- 64 GB DDR4 ECC memory supports demanding workloads
- 12 large-form-factor bays provide high storage capacity
- Dual 800 W hot-plug supplies ensure power redundancy
- HPE iLO Advanced enables remote server management
Caractéristiques
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.6GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 64GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 3TB |
| Hard Drive (Installed) | 2,00 |
| Storage Controller | HP Smart Array P440ar And Sas Expander |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
What drive interface does the P440ar controller support and what throughput does it cap at?
The P440ar SAS controller supports SATA drives and caps at 12 Gb/s per lane.
What physical space and rail kit are required to mount this 12 LFF chassis?
The 12 LFF chassis measures 36 x 24 x 10 in and weighs 40 lb; a rail kit is available on request.
How is the server installed in a rack and what step is often missed?
Mount the rail kit first, slide the server in, connect dual 800 W power supplies and network cables, then activate iLO for remote management.
