HPE
HPE ProLiant DL380 Gen9 4LFF 2× Xeon E5-2699 v3 256GB DDR4
2U rack server with dual 18-core Xeon processors at 2.3 GHz, 256 GB DDR4 ECC memory, P440 SAS controller and four 3.5-inch drive bays
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.3GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size256GB
- Dual 18-core Xeon processors deliver 36 threads for heavy workloads
- 256GB DDR4 ECC memory supports large datasets and virtualization
- HPE Smart Array P440 SAS controller manages up to four 3.5-inch drives
- Integrated iLO Advanced remote management enables out-of-band server control
- Two 500W redundant power supplies maintain uptime during power events
HPE ProLiant DL380 Gen9 4LFF Server
The HPE ProLiant DL380 Gen9 4LFF is a rack-mount server system built for compute-intensive workloads. It ships with two Intel Xeon E5-2699 v3 processors running at 2.3GHz, each delivering 18 cores and 45MB cache. The system includes 256GB of DDR4 ECC Registered memory and an HPE Smart Array P440 SAS controller.
Suits dense virtualisation and database tasks.
This configuration suits organisations running dense virtualisation, large databases or high-thread-count applications that benefit from 36 total cores and large memory capacity. The integrated graphics and lack of installed drives mean it is not for GPU-accelerated workloads, workstations needing local high-speed scratch space, or deployments requiring more than four 3.5-inch drive bays.
Four 3.5-inch drive bays with P440 SAS controller
The chassis provides four 3.5-inch LFF bays connected to the P440 PCIe SAS controller, which manages SATA and SAS media in RAID configurations. Storage capacity and performance scale with the drives you add, so the right part depends on matching your dataset size and I/O profile to the four-bay limit.
Points forts
- Dual 18-core Xeon processors deliver 36 threads for heavy workloads
- 256GB DDR4 ECC memory supports large datasets and virtualization
- HPE Smart Array P440 SAS controller manages up to four 3.5-inch drives
- Integrated iLO Advanced remote management enables out-of-band server control
- Two 500W redundant power supplies maintain uptime during power events
Caractéristiques
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.3GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 256GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 3TB |
| Hard Drive (Installed) | 4,00 |
| Storage Controller | HPE Smart Array P440 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
At what core temperature do the Xeon E5-2699 v3 processors begin to throttle under sustained full load?
The 18-core Xeon E5-2699 v3 CPUs reduce frequency when their internal thermal limit is reached, protecting the 2.3 GHz base clock during continuous operation.
What is the combined power draw of the two 500 W Flex Slot supplies when the server runs at full load all day?
Each 500 W Flex Slot unit shares the load, so the system can draw up to the rated capacity of the redundant pair during sustained peak utilisation.
Which drive trays and caddies must be sourced separately to populate the four 3.5-inch bays?
The 4 LFF chassis ships without drive carriers; standard 3.5-inch SAS or SATA trays compatible with the P440 controller are required to install storage.
