HPE
HPE ProLiant DL380 Gen9 4LFF 2x Xeon E5-2683 v4 768GB DDR4 rack server
Rack server with dual Xeon E5-2683 v4 processors, 768 GB DDR4 memory, four 3.5-inch drive bays and a Smart Array P440 SAS controller
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.1GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size768GB
- Dual Xeon E5-2683 v4 CPUs deliver 32 total cores for heavy workloads
- 768 GB DDR4 ECC registered memory supports large virtualisation environments
- HPE Smart Array P440 SAS controller manages up to 4 LFF drives
- Integrated iLO Advanced enables full remote server management
- Dual 500 W Flex Slot power supplies provide redundant power
Dual-socket Xeon server with massive memory
The HPE ProLiant DL380 Gen9 4LFF chassis ships with two Xeon E5-2683 v4 processors running at 2.1GHz and 768GB of DDR4 ECC registered memory. This configuration targets virtualisation clusters, in-memory databases and compute-heavy workloads that need many cores and large RAM capacity in a 2U rack form factor.
Upgrade from single-socket or lower-core systems
Replacing a single-socket server or a dual-socket box with fewer cores and less memory removes licensing bottlenecks and reduces node count for the same throughput. The jump is worth it when workloads scale across 32 total cores and benefit from the 3TB maximum memory ceiling for future growth.
768GB DDR4 handles large VM fleets and analytics
The installed memory comfortably runs dozens of virtual machines, large Java heaps or Spark executors without swapping. Headroom runs out when datasets exceed the 3TB platform limit or when storage I/O saturates the P440 SAS controller and 1GbE 332T network links.
Points forts
- Dual Xeon E5-2683 v4 CPUs deliver 32 total cores for heavy workloads
- 768 GB DDR4 ECC registered memory supports large virtualisation environments
- HPE Smart Array P440 SAS controller manages up to 4 LFF drives
- Integrated iLO Advanced enables full remote server management
- Dual 500 W Flex Slot power supplies provide redundant power
Caractéristiques
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.1GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 768GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 3TB |
| Hard Drive (Installed) | 16,00 |
| Storage Controller | HPE Smart Array P440 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
What are the exact chassis dimensions for rack-mount planning?
The unit measures 36 x 24 x 10 in and weighs 40, so verify cabinet depth and load rating before installation.
How are the two Xeon E5-2683 v4 processors and 768GB DDR4 memory installed at the factory?
Both CPUs and all DDR4 ECC registered modules are pre-installed and tested; the only step required on site is seating the server on rails and connecting power and network cables.
Which drive bays and controller will need attention when adding storage later?
The 4LFF chassis provides four 3.5-inch SATA bays driven by the HPE Smart Array P440 SAS controller; plan for drive carriers and RAID configuration when populating them.
