HPE
HPE ProLiant DL380 Gen9 8SFF rack server 1x Xeon E5-2697 v3 2.6GHz 384GB DDR4 no drive
A 2U rack server holding eight 2.5-inch drive bays with a 14-core 2.6 GHz Xeon E5-2697 v3 and 384 GB DDR4 memory
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.6GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size384GB
- 14-core Xeon E5-2697 v3 at 2.6GHz drives demanding workloads
- 384GB DDR4 ECC registered memory supports large datasets
- Eight 2.5-inch drive bays with P440 SAS controller enable flexible storage
- Dual 10GbE plus dual 1GbE ports provide high-throughput networking
- iLO Advanced remote management simplifies server administration
DL380 Gen9 8SFF 14-core Xeon server
This 2U rack server ships with a single Intel Xeon E5-2697 v3 processor running at 2.6 GHz with 14 cores and 35 MB cache. It includes 384 GB of DDR4 ECC registered memory and an HPE Smart Array P440 SAS controller that supports up to eight 2.5-inch SATA drive bays. Remote management is provided by HPE iLO Advanced and the unit carries two 500 W Flex Slot power supplies.
Suits virtualisation hosts needing high core
The 14-core CPU and 384 GB RAM fit dense virtualisation, database or container workloads that benefit from many threads and ECC protection. The single-socket layout leaves a second processor socket open for future expansion. Buyers who want more storage than eight 2.5-inch bays provide or who need GPU accelerators should look at a different platform.
Single Xeon E5-2697 v3 with 384 GB DDR4 ECC
The installed processor delivers 14 cores at 2.6 GHz with 35 MB cache, and the memory population uses DDR4 ECC registered DIMMs up to the 384 GB shown. This combination of core count, clock speed and memory capacity is the primary factor in deciding whether the server matches the workload.
Points forts
- 14-core Xeon E5-2697 v3 at 2.6GHz drives demanding workloads
- 384GB DDR4 ECC registered memory supports large datasets
- Eight 2.5-inch drive bays with P440 SAS controller enable flexible storage
- Dual 10GbE plus dual 1GbE ports provide high-throughput networking
- iLO Advanced remote management simplifies server administration
Caractéristiques
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.6GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 384GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 3TB |
| Hard Drive (Installed) | 4,00 |
| Storage Controller | HPE Smart Array P440 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
Will the single Xeon E5-2697 v3 leave enough PCIe lanes for my existing HPE Smart Array P440 SAS Controller and dual 10 GbE ports?
The 14-core Xeon E5-2697 v3 provides 40 PCIe 3.0 lanes; the P440 uses eight lanes and the Intel X540 dual 10 GbE card uses another eight, leaving ample bandwidth for additional cards.
How can I confirm the 384 GB DDR4 ECC Registered memory is detected and healthy after first boot?
During POST the iLO console displays each DIMM slot, capacity and speed; the System Health LED stays green and iLO logs show zero correctable errors when all 384 GB are operational.
Does the box include drive caddies for the eight 2.5-inch bays or must I order them separately?
The 8SFF chassis ships with eight drive caddies installed; drives themselves are not included and must be purchased separately.
