HPE
HPE ProLiant ML350 Gen10 8SFF 2x Xeon Gold 5218R 512GB DDR4 rack server
Dual Xeon Gold 5218R 2.1 GHz 20-core server with 512 GB DDR4 ECC memory, Smart Array P408 SAS controller and eight 2.5-inch drive bays
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.1 GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size512GB
- Dual Xeon Gold 5218R processors deliver 40 cores at 2.1 GHz
- 512 GB DDR4 ECC memory supports large workloads with room to 3 TB
- Eight 2.5-inch drive bays with Smart Array P408 SAS controller
- Dual 10 GbE plus dual 1 GbE Intel network adapters built in
- Redundant 500 W Flex Slot power supplies and iLO Advanced remote management
Dual Xeon Gold 5218R server
The HPE ProLiant ML350 Gen10 is a rack-mount server built around two Intel Xeon Gold 5218R processors running at 2.1 GHz. Each CPU provides 20 cores and 27.5 MB of cache, giving 40 threads for parallel workloads. It ships with 512 GB of DDR4 ECC registered memory and supports up to 3 TB total. The chassis holds eight 2.5-inch drive bays and includes an HPE Smart Array P408 SAS controller. Remote management is handled by HPE iLO Advanced.
Sustained-load behaviour
Dual 500 W Flex Slot power supplies feed the system, and firmware is updated to the latest stable version before dispatch. A full burn-in test verifies stability under continuous demand. The Smart Array P408 controller manages RAID across SATA or SAS drives without a listed cache size. Integrated graphics handle console output without adding thermal load. Network connectivity uses an Intel I350 and X540 combination providing two 10 GbE and two 1 GbE ports for steady throughput.
Pre-order checks
Confirm that your rack can accommodate the 36 x 24 x 10 in form factor and the 40 lb weight. The eight 2.5-inch bays accept SATA or SAS drives; no drives are installed so you must supply them. Memory expansion uses DDR4 ECC registered modules only. A rail kit is available on request but not included. Ensure your environment provides adequate cooling and power distribution for dual supplies.
Points forts
- Dual Xeon Gold 5218R processors deliver 40 cores at 2.1 GHz
- 512 GB DDR4 ECC memory supports large workloads with room to 3 TB
- Eight 2.5-inch drive bays with Smart Array P408 SAS controller
- Dual 10 GbE plus dual 1 GbE Intel network adapters built in
- Redundant 500 W Flex Slot power supplies and iLO Advanced remote management
Caractéristiques
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.1 GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 512GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 3TB |
| Hard Drive (Installed) | 8,00 |
| Storage Controller | HPE Smart Array P408 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
How much heat do the two 20-core Xeon Gold 5218R CPUs and 512GB DDR4 produce under continuous load?
The chassis uses two 500W Flex Slot power supplies and integrated system fans managed by HPE iLO to cool the dual 2.1 GHz processors and memory under sustained operation.
Which drive caddies and SAS cables are required to populate the 8 SFF bays with SATA drives?
The 8 SFF bays accept 2.5-inch SATA drives; the Smart Array P408 SAS controller provides the internal SAS connectivity, so only standard HPE drive carriers are needed.
Will the Intel I350/X540 network card with 2x 10GbE and 2x 1GbE ports work with my existing Cat5e patch panel?
The 1GbE ports operate over Cat5e; the 10GbE ports require Cat6a or better for full speed, but will fall back to 1GbE on Cat5e.
