Intel Xeon Max 9468 server processor, silver rectangular chip with gold contacts and green substrate

Intel

Intel PK8071305223400 Xeon Max 9468 server processor 48-core 2.1 GHz 105 MB L3 350 W

SKU CH-EVMR-13BEA MPN PK8071305223400

48-core server processor with 96 threads, 105 MB L3 cache, 2.1 GHz base frequency, 3.5 GHz max turbo, 8-channel DDR5 support up to 4 TB, PCIe 5.0 with 80 lanes, and 350 W TDP

  • NameXeon Max 9468
  • CPU Socket TypeLGA 4677
  • Core NameSapphire Rapids
  • # of Cores48-Core
  • # of Threads96
  • Operating Frequency2.1 GHz
  • 48 cores and 96 threads handle parallel workloads
  • 5 GHz max turbo frequency accelerates single-thread performance
  • 105 MB L3 cache reduces data-access latency
  • Eight-channel DDR5 up to 4800 MT/s feeds memory-intensive applications
  • PCIe 5.0 with 80 lanes enables high-bandwidth I/O expansion

48-core Xeon Max for dense compute

The Intel Xeon Max 9468 delivers 48 cores and 96 threads at a 2.1 GHz base frequency with a 3.5 GHz maximum turbo. A 105 MB L3 cache feeds data to every core while the 10 nm Sapphire Rapids architecture supports 64-bit processing and Intel AMX, AVX-512, AVX2, AVX and SSE4.2 instructions. The processor is built for dual-socket servers that need maximum core density in a single package.

DDR5-4800 controller with eight channels

The integrated memory controller runs DDR5 at up to 4800 MT/s with one DIMM per channel and 4400 MT/s with two DIMMs per channel across eight channels, reaching a 4 TB maximum capacity. PCI Express 5.0 supplies 80 lanes for high-bandwidth accelerators, storage or networking. The 350 W thermal design power sets a firm ceiling that the platform cooling must meet.

LGA 4677 socket requires server-grade cooling

The LGA 4677 land-grid array seats the chip in purpose-built server boards; no cooling device is included. Installation demands a validated heatsink or liquid cold plate rated for the full 350 W dissipation and a chassis airflow plan that sustains it. The 2S scalability link enables a second identical processor for doubled thread count and memory channels.

Points forts

  • 48 cores and 96 threads handle parallel workloads
  • 5 GHz max turbo frequency accelerates single-thread performance
  • 105 MB L3 cache reduces data-access latency
  • Eight-channel DDR5 up to 4800 MT/s feeds memory-intensive applications
  • PCIe 5.0 with 80 lanes enables high-bandwidth I/O expansion

Caractéristiques

BrandIntel
SeriesIntel Xeon Max
NameXeon Max 9468
ModelPK8071305223400
CPU Socket TypeLGA 4677
Core NameSapphire Rapids
# of Cores48-Core
# of Threads96
Operating Frequency2.1 GHz
Max Turbo Frequency3.5 GHz
L3 Cache105MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedUp to DDR5 4800 MT/s 1DPC
Up to DDR5 4400 MT/s 2DPC
Maximum Memory Capacity4TB
Memory Channel8 Channel
Virtualization Technology SupportYes
Scalability2S
PCI Express Revision5.0
Max # of PCI Express Lanes80
Multimedia InstructionIntel AMX, Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512
Thermal Design Power350W
Cooling DeviceCooling device not included - Processor Only
Poids d’expédition0.23 kg
Dimensions du colis127 × 102 × 13 mm

Questions sur cet article

Should I choose the 48-core 9468 or a lower-core Xeon Max for my workload?

The 9468 delivers 48 cores and 96 threads at 2.1 GHz base with 3.5 GHz turbo, giving the highest thread count in the Xeon Max line for heavily parallel server tasks.

What does the 3.5 GHz turbo mean once the chip is installed in a server?

Under load the processor can lift up to 3.5 GHz on active cores, limited by the 350 W thermal envelope and your cooling solution.

How does the PCIe 5.0 interface cap real-world expansion?

The CPU exposes 80 lanes of PCIe 5.0, so total I/O bandwidth is limited by those lanes and the 5.0 signalling rate.
