Intel Xeon Gold 5315Y server CPU, silver heat spreader, LGA 4189 socket, gold contact pads

Intel

Intel Xeon Gold 5315Y 8-core 3.2 GHz LGA 4189 140W CD8068904665802 server processor

SKU CH-6PZS-F766Z MPN CD8068904665802

Eight-core Ice Lake server processor with 16 threads, 3.2 GHz base clock, 12 MB L3 cache and eight-channel DDR4-2933 support in a 140 W LGA 4189 package

  • NameXeon Gold 5315Y
  • CPU Socket TypeLGA 4189
  • Core NameIce Lake
  • # of Cores8-Core
  • # of Threads16
  • Operating Frequency3.2 GHz
  • 8 cores and 16 threads handle parallel workloads efficiently
  • 2 GHz base frequency with 3.60 GHz max turbo boost for responsive performance
  • 10 nm Ice Lake architecture delivers modern compute density
  • 8-channel DDR4 2933 memory controller supports high bandwidth
  • 64 PCIe 4.0 lanes enable fast I/O expansion

Eight-core Ice Lake server CPU

The Intel Xeon Gold 5315Y is an 8-core, 16-thread processor built on 10 nm Ice Lake architecture for LGA 4189 sockets. It runs at a 3.2 GHz base frequency with a 3.60 GHz maximum turbo and includes 12MB of L3 cache. This unit suits single-socket or dual-socket servers handling virtualization, cloud workloads or database tasks.

DDR4 2933 eight-channel memory and PCIe 4.0 lanes

The integrated memory controller supports DDR4 2933 across eight channels, capping memory bandwidth at that speed. PCI Express revision 4.0 provides up to 64 lanes for add-in cards, storage controllers or accelerators. Platforms requiring faster memory speeds, more channels or PCIe 5.0 connectivity cannot use this processor.

Replaces earlier Xeon Gold

The part upgrades systems currently running lower-core-count Ice Lake or Cascade Lake CPUs where higher thread density and 140W thermal headroom improve consolidation ratios. It is not suited for workloads demanding more than 8 cores, higher base clocks or memory speeds beyond DDR4 2933.

Points forts

  • 8 cores and 16 threads handle parallel workloads efficiently
  • 2 GHz base frequency with 3.60 GHz max turbo boost for responsive performance
  • 10 nm Ice Lake architecture delivers modern compute density
  • 8-channel DDR4 2933 memory controller supports high bandwidth
  • 64 PCIe 4.0 lanes enable fast I/O expansion

Caractéristiques

BrandIntel
SeriesIntel Xeon Gold
NameXeon Gold 5315Y
ModelCD8068904665802
CPU Socket TypeLGA 4189
Core NameIce Lake
# of Cores8-Core
# of Threads16
Operating Frequency3.2 GHz
Max Turbo Frequency3.60 GHz
L3 Cache12MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedDDR4 2933
Memory Channel8 Channel
Virtualization Technology SupportYes
PCI Express Revision4.0
Max # of PCI Express Lanes64
Thermal Design Power140W
Poids d’expédition0.09 kg
Dimensions du colis116 × 101 × 44 mm

Questions sur cet article

How do I decide between the 3.2 GHz base and 3.60 GHz turbo speeds?

The 3.2 GHz base clock is the guaranteed all-core frequency under load, while the 3.60 GHz max turbo applies when fewer cores are active and thermal headroom exists.

What does the 140 W TDP mean for my server cooling and power budget?

A 140 W TDP indicates the sustained heat the cooler must dissipate and the power the VRM must deliver; plan airflow and PSU capacity accordingly.

What bandwidth does the PCIe 4.0 interface with 64 lanes provide for add-in cards?

PCIe 4.0 doubles the per-lane throughput of PCIe 3.0, and 64 lanes allow multiple x16 GPUs or storage controllers without sharing bandwidth.
