Square green PCB with silver metal heat spreader and gold contact pads on the underside

Intel

Intel Xeon Gold 6336Y server processor BX806896336Y

SKU CH-TFWS-CPFXX MPN BX806896336Y

A 24-core server processor with 48 threads, 36 MB L3 cache and 3.60 GHz max turbo frequency on a 10 nm Ice Lake core

  • NameXeon Gold 6336Y
  • CPU Socket TypeLGA 4189
  • Core NameIce Lake
  • # of Cores24-Core
  • # of Threads48
  • Operating Frequency2.4 GHz
  • 24 cores and 48 threads handle parallel workloads efficiently
  • 4 GHz base with 3.60 GHz max turbo frequency for responsive compute
  • 36 MB L3 cache reduces latency on large data sets
  • 8-channel DDR4 3200 controller supports up to 6 TB memory
  • PCIe 4.0 with 64 lanes enables high-throughput I/O expansion

Xeon Gold 6336Y 24-core server processor

The Intel Xeon Gold 6336Y is a 24-core, 48-thread server CPU built on 10 nm Ice Lake architecture. It runs at a 2.4 GHz base frequency with a 3.60 GHz maximum turbo and provides 36 MB of L3 cache. The processor fits the LGA 4189 socket and supports eight-channel DDR4-3200 memory up to 6 TB. It delivers 64 lanes of PCI Express 4.0 and is rated at 185 W TDP.

Suits dual-socket 2S servers needing high thread

This processor suits dual-socket servers that require 48 threads per socket and large memory capacity through eight DDR4 channels. It is not for single-socket builds that cannot use the 2S scalability, nor for platforms that need integrated graphics or support a different socket. Buyers who want more than 64 PCIe lanes per CPU or a lower thermal envelope should look at something else.

LGA 4189 socket and 185 W TDP define platform fit

The LGA 4189 socket and 185 W thermal design power are the decisive specifications for motherboard and cooling selection. A compatible server board with the LGA 4189 socket and a cooling solution rated for at least 185 W are mandatory. Without these the processor cannot be installed or operated within its thermal limits.

Points forts

  • 24 cores and 48 threads handle parallel workloads efficiently
  • 4 GHz base with 3.60 GHz max turbo frequency for responsive compute
  • 36 MB L3 cache reduces latency on large data sets
  • 8-channel DDR4 3200 controller supports up to 6 TB memory
  • PCIe 4.0 with 64 lanes enables high-throughput I/O expansion

Caractéristiques

BrandIntel
SeriesIntel Xeon Gold
NameXeon Gold 6336Y
ModelBX806896336Y
CPU Socket TypeLGA 4189
Core NameIce Lake
# of Cores24-Core
# of Threads48
Operating Frequency2.4 GHz
Max Turbo Frequency3.60 GHz
L3 Cache36MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedDDR4 3200
Maximum Memory Capacity6TB
Memory Channel8 Channel
Virtualization Technology SupportYes
Scalability2S
PCI Express Revision4.0
Max # of PCI Express Lanes64
Thermal Design Power185W
Cooling DeviceCooling device not included - Processor Only
Poids d’expédition0.09 kg
Dimensions du colis116 × 101 × 44 mm

Questions sur cet article

Which variant should I choose for a dual-socket server that needs maximum memory capacity?

This single SKU is a 24-core Ice Lake part rated for 2S scalability, supporting up to 6 TB of DDR4 across eight channels when paired with a compatible motherboard.

How does the 2.4 GHz base clock and 3.60 GHz max turbo behave under sustained multi-threaded workloads?

The 24 cores and 48 threads run at 2.4 GHz base with a 3.60 GHz max turbo; actual sustained speeds depend on the 185 W thermal envelope and the cooler installed.

What does PCIe 4.0 with 64 lanes cap in practice for I/O expansion?

The processor provides 64 lanes of PCI Express 4.0, limiting total I/O bandwidth to the Gen 4 signalling rate per lane for GPUs, storage or networking cards.
