Silver rectangular server processor with gold contact pads and green substrate visible on LGA 4189 socket package

Intel

Intel Xeon Gold 6354 3.0 GHz 18-Core LGA 4189 205W CD8068904571601 server processor

SKU CH-JXGN-R7FC4 MPN CD8068904571601

18-core server processor with 3.0 GHz base clock, 39 MB L3 cache and eight-channel DDR4 3200 support

  • NameXeon Gold 6354
  • CPU Socket TypeLGA 4189
  • Core NameIce Lake
  • # of Cores18-Core
  • # of Threads36
  • Operating Frequency3.0 GHz
  • 18 cores and 36 threads handle parallel workloads efficiently
  • 0 GHz base with 3.60 GHz turbo boost speeds single-thread tasks
  • 39 MB L3 cache reduces latency for data-intensive apps
  • 8-channel DDR4 3200 controller feeds memory bandwidth to all cores
  • 64 PCIe 4.0 lanes connect high-speed storage and accelerators

Server processor for multi-socket workloads

The Intel Xeon Gold 6354 is an 18-core, 36-thread CPU built on 10 nm Ice Lake architecture. It runs at a 3.0 GHz base frequency with a 3.60 GHz max turbo and provides 39MB of L3 cache. The 205W TDP targets dual-socket servers handling virtualisation, database or compute tasks.

Installation notes for LGA 4189

The processor seats in an LGA 4189 socket using the platform's retention mechanism; no consumer-style lever is present. Correct torque on the heatsink mounting hardware is critical because uneven pressure can damage the substrate or cause thermal throttling under the 205W design power.

Platform requirements before ordering

Verify the motherboard supports the LGA 4189 socket and delivers 8-channel DDR4 3200 memory population for full bandwidth. Confirm the BIOS revision enables the Ice Lake core and that the power-delivery subsystem is rated for 205W continuous operation. Ensure the chassis airflow and cooler clearance match the thermal envelope.

Points forts

  • 18 cores and 36 threads handle parallel workloads efficiently
  • 0 GHz base with 3.60 GHz turbo boost speeds single-thread tasks
  • 39 MB L3 cache reduces latency for data-intensive apps
  • 8-channel DDR4 3200 controller feeds memory bandwidth to all cores
  • 64 PCIe 4.0 lanes connect high-speed storage and accelerators

Caractéristiques

BrandIntel
SeriesIntel Xeon Gold
NameXeon Gold 6354
ModelCD8068904571601
CPU Socket TypeLGA 4189
Core NameIce Lake
# of Cores18-Core
# of Threads36
Operating Frequency3.0 GHz
Max Turbo Frequency3.60 GHz
L3 Cache39MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedDDR4 3200
Memory Channel8 Channel
Virtualization Technology SupportYes
PCI Express Revision4.0
Max # of PCI Express Lanes64
Thermal Design Power205W
Poids d’expédition0.09 kg
Dimensions du colis116 × 101 × 44 mm

Questions sur cet article

How can I verify the Xeon Gold 6354 is running at its 3.0 GHz base frequency after installation?

Check the CPU frequency in BIOS or use a monitoring tool such as lscpu on Linux or Task Manager on Windows; it should report 3.0 GHz at idle and up to 3.60 GHz under load.

What comes in the box with the CD8068904571601 and what must I purchase separately?

The tray processor is supplied alone; you must buy a compatible LGA 4189 heatsink rated for 205W and DDR4 3200 memory modules separately.

Which memory configuration should I choose for the 8-channel controller on this 18-core Xeon?

Populate all eight channels with identical DDR4 3200 DIMMs to obtain maximum bandwidth for the 18-core 3.0 GHz processor.
