Square green circuit board with gold contact pads and silver heat spreader marked Intel Xeon Platinum 8470N

Intel

Intel Xeon Platinum 8470N PK8071305075201 server processor 52-core 1.7 GHz 97.5 MB L3 300 W

SKU CH-VEBY-3DFXV MPN PK8071305075201

52-core server processor reaching 3.6 GHz turbo with 97.5 MB L3 cache and 300 W TDP

  • NameXeon Platinum 8470N
  • CPU Socket TypeLGA 4677
  • Core NameSapphire Rapids
  • # of Cores52-Core
  • # of Threads104
  • Operating Frequency1.7 GHz
  • 52 cores and 104 threads handle heavy parallel workloads
  • 7 GHz base with 3.6 GHz max turbo balances efficiency and peak speed
  • 5 MB L3 cache keeps large datasets close to the cores
  • Eight-channel DDR5 up to 4800 MT/s feeds data-intensive applications
  • PCIe 5.0 with 80 lanes enables high-bandwidth I/O expansion

Server-grade compute core

The Intel Xeon Platinum 8470N is a 52-core processor built for dual-socket servers that run heavily threaded workloads. Its 104 threads and 97.5 MB L3 cache suit virtualization hosts, database nodes and high-performance computing clusters.

Platform integration needs

The chip drops into an LGA 4677 socket and exposes 80 lanes of PCI Express 5.0 for accelerator cards and fast storage. Eight memory channels accept DDR5 at up to 4800 MT/s with one DIMM per channel or 4400 MT/s with two, so the board must provide matching slots and robust power delivery for the 300 W thermal design power.

Memory and throughput ceiling

Maximum supported capacity reaches 4 TB of DDR5 across the eight channels, giving ample headroom for in-memory databases and large VM fleets. The 1.7 GHz base frequency and 3.6 GHz max turbo frequency deliver steady throughput, while the 300 W envelope and lack of included cooling mean the chassis must supply adequate airflow.

Points forts

  • 52 cores and 104 threads handle heavy parallel workloads
  • 7 GHz base with 3.6 GHz max turbo balances efficiency and peak speed
  • 5 MB L3 cache keeps large datasets close to the cores
  • Eight-channel DDR5 up to 4800 MT/s feeds data-intensive applications
  • PCIe 5.0 with 80 lanes enables high-bandwidth I/O expansion

Caractéristiques

BrandIntel
SeriesIntel Xeon Platinum
NameXeon Platinum 8470N
ModelPK8071305075201
CPU Socket TypeLGA 4677
Core NameSapphire Rapids
# of Cores52-Core
# of Threads104
Operating Frequency1.7 GHz
Max Turbo Frequency3.6 GHz
L3 Cache97.5MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedUp to DDR5 4800 MT/s 1DPC
Up to DDR5 4400 MT/s 2DPC
Maximum Memory Capacity4TB
Memory Channel8 Channel
Virtualization Technology SupportYes
Scalability2S
PCI Express Revision5.0
Max # of PCI Express Lanes80
Thermal Design Power300W
Cooling DeviceCooling device not included - Processor Only
Poids d’expédition0.23 kg
Dimensions du colis127 × 102 × 25 mm

Questions sur cet article

Will the 300 W thermal design power force the 52-core processor to throttle during continuous all-core workloads?

The 300 W TDP is the sustained power limit; with adequate cooling the 52 cores can run at base 1.7 GHz indefinitely without thermal throttling.

How loud and hot does the Xeon Platinum 8470N get when the 104 threads run 24/7 at 3.6 GHz turbo?

No cooler is included; noise and temperature depend entirely on the chosen heatsink or liquid loop rated for 300 W continuous dissipation.

Which DDR5 memory kit must I already own to populate the 8-channel controller at 4800 MT/s?

Eight DDR5-4800 modules, one per channel (1 DPC), are required to reach the rated 4800 MT/s speed across all 8 channels.
