Gold square server processor with silver heat spreader and LGA 4677 socket contacts

Intel

Intel Xeon Platinum 8470Q PK8071305072301 52-core 2.1 GHz server processor

SKU CH-5AQE-FGJQ6 MPN PK8071305072301

A 52-core server processor with 104 threads, 2.1 GHz base and 3.8 GHz turbo, 105 MB L3 cache, eight-channel DDR5 support up to 4 TB, and 80 PCIe 5.0 lanes in an LGA 4677 socket

  • NameXeon Platinum 8470Q
  • CPU Socket TypeLGA 4677
  • Core NameSapphire Rapids
  • # of Cores52-Core
  • # of Threads104
  • Operating Frequency2.1 GHz
  • 52 cores and 104 threads handle heavy parallel workloads
  • 1 GHz base with 3.8 GHz max turbo adapts to burst demand
  • 105 MB L3 cache keeps large datasets close to execution units
  • Eight-channel DDR5 up to 4800 MT/s feeds memory-bound applications
  • 80 PCIe 5.0 lanes provide high-bandwidth I/O for accelerators and storage

Scalable 2S server processor

The Intel Xeon Platinum 8470Q is a 52-core server CPU built for two-socket platforms. It delivers 104 threads at a 2.1 GHz base frequency with a 3.8 GHz max turbo. The LGA 4677 socket supports eight DDR5 channels and up to 4 TB of memory. This processor targets data-centre workloads that need high core density and large memory capacity.

Sustained multi-threaded throughput

Under continuous load the 52 cores maintain the 2.1 GHz base clock across all threads. The 105 MB L3 cache reduces latency for memory-bound tasks while the eight-channel DDR5 controller feeds data at up to 4800 MT/s per channel. PCIe 5.0 with 80 lanes provides high-bandwidth I/O for storage and accelerators without bottlenecks during extended runs.

Thermal envelope and power profile

The processor carries a 350 W thermal design power and ships without a cooling device. System integrators must provide a solution rated for that heat output in a dual-socket chassis. Power draw scales with active core count and memory traffic, so adequate airflow and voltage regulation are essential for stable operation at the 10 nm manufacturing node.

Points forts

  • 52 cores and 104 threads handle heavy parallel workloads
  • 1 GHz base with 3.8 GHz max turbo adapts to burst demand
  • 105 MB L3 cache keeps large datasets close to execution units
  • Eight-channel DDR5 up to 4800 MT/s feeds memory-bound applications
  • 80 PCIe 5.0 lanes provide high-bandwidth I/O for accelerators and storage

Caractéristiques

BrandIntel
SeriesIntel Xeon Platinum
NameXeon Platinum 8470Q
ModelPK8071305072301
CPU Socket TypeLGA 4677
Core NameSapphire Rapids
# of Cores52-Core
# of Threads104
Operating Frequency2.1 GHz
Max Turbo Frequency3.8 GHz
L3 Cache105MB
64-Bit SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedUp to DDR5 4800 MT/s 1DPC
Up to DDR5 4400 MT/s 2DPC
Maximum Memory Capacity4TB
Memory Channel8 Channel
Virtualization Technology SupportYes
Scalability2S
PCI Express Revision5.0
Max # of PCI Express Lanes80
Thermal Design Power350W
Cooling DeviceCooling device not included - Processor Only
Poids d’expédition0.23 kg
Dimensions du colis127 × 102 × 25 mm

Questions sur cet article

How much heat does the 350 W Xeon Platinum 8470Q produce under sustained load?

The processor has a thermal design power of 350 W, so sustained full-load operation will dissipate that much heat and requires a server-grade cooling solution rated for at least 350 W.

What memory must I already own for the 8-channel DDR5 controller to run at 4800 MT/s?

You need DDR5 RDIMMs rated for 4800 MT/s; populate one DIMM per channel across all eight channels to reach the 1DPC speed of 4800 MT/s.

Will the LGA 4677 socket and PCIe 5.0 lanes work with my existing dual-socket Sapphire Rapids board?

Yes, the CPU fits the LGA 4677 socket, supports 2S scalability and provides 80 lanes of PCIe 5.0, matching a dual-socket Sapphire Rapids platform.
