Green rectangular M.2 2280 SSD with exposed chips and gold edge connector

KingSpec

KingSpec NX-128 2280 128GB PCIe 3.0 x4 NVMe 1.3 internal SSD

SKU CH-JM9P-ZW87B

M.2 2280 128GB NVMe SSD with PCIe 3.0 x4 interface, up to 2200 MBps read and 800 MBps write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity128GB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4

Options NX-128-2280

  • Up to 2200 MB/s sequential read accelerates boot and load times
  • Up to 800 MB/s sequential write handles large file saves efficiently
  • 380,000 random read IOPS keeps multitasking responsive
  • 320,000 random write IOPS sustains performance under heavy write workloads
  • 60 TBW and 1,000,000-hour MTBF indicate long service life

Capacity and interface

The KingSpec NX-128 2280 is a 128GB internal SSD built on the M.2 2280 form factor with a PCIe 3.0 x4 interface and NVMe 1.3 protocol. It targets desktop and laptop users who need a compact boot or secondary drive for everyday workloads.

Sustained workload behaviour

The drive uses 3D NAND flash and supports HMB technology to maintain performance without a dedicated DRAM cache. Rated endurance is 60TB written and the MTBF is 1000000 hours, indicating consistent operation across long write sessions within the 0°C to 70°C operating range.

Deciding specification

The PCIe 3.0 x4 NVMe 1.3 interface delivers sequential reads up to 2200 MBps and writes up to 800 MBps, with random performance of 380000 read IOPS and 320000 write IOPS. This single interface and speed profile determines whether the drive matches the host system and workload requirements.

Points forts

  • Up to 2200 MB/s sequential read accelerates boot and load times
  • Up to 800 MB/s sequential write handles large file saves efficiently
  • 380,000 random read IOPS keeps multitasking responsive
  • 320,000 random write IOPS sustains performance under heavy write workloads
  • 60 TBW and 1,000,000-hour MTBF indicate long service life

Caractéristiques

BrandKingSpec
SeriesNX 2280 Series
ModelNX-128 2280
Part NumberNX-128 2280
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity128GB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4
ProtocolNVMe 1.3
Max Sequential ReadUp to 2200 MBps
Max Sequential WriteUp to 800 MBps
4KB Random ReadUp to 380,000 IOPS
4KB Random WriteUp to 320,000 IOPS
Terabytes Written (TBW)60TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5-95%
Height2.10mm
Width22.00mm
Depth80.00mm
Weight50g

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Does the drive run hotter without a heatsink when it handles sustained NVMe workloads all day?

The KingSpec NX-128 2280 ships without a heatsink and is rated for 0 °C to 70 °C operating temperature, so sustained NVMe 1.3 loads will rely on your motherboard airflow to stay within that range.

What motherboard slot and protocol does this 128 GB M.2 2280 drive need to function?

It requires an M.2 2280 slot wired for PCI-Express 3.0 x4 with NVMe 1.3 support; a SATA-only M.2 slot will not work.

Will the PCIe 3.0 x4 interface slow down older SATA SSDs I keep in the same system?

The NX-128 2280 uses its own PCIe 3.0 x4 lanes and NVMe 1.3 controller, so it does not share bandwidth with or affect any SATA drives already installed.
