Small green circuit board with USB plug, onboard microphone and speaker header

LORDWORLD

LORDWORLD USB Sound Card Audio Module Onboard Microphone development board

SKU CH-EGDH-RCSEY

Driver-free USB audio module with onboard microphone and speaker header supports sampling rates from 8K to 48K Hz for Raspberry Pi and Jetson Nano

  • Driver-free USB 2.0 audio for instant Raspberry Pi and Jetson Nano setup
  • Onboard microphone plus speaker header enables recording and playback in one module
  • Stereo codec supports sampling rates from 8K up to 48K Hz
  • Works with Windows 7 through 10, Mac OS, Linux, Android and WinCE
  • Compact plug-and-play design adds sound without extra drivers or power

USB Audio Module For Raspberry Pi And Jetson Nano

This compact USB sound card adds stereo recording and playback to Raspberry Pi or Jetson Nano boards. It connects through a standard USB 2.0 port and operates without drivers on Windows, Mac OS, Linux, Android and WinCE. An onboard microphone and a speaker header provide immediate audio input and output for voice projects.

Onboard Microphone And Speaker Header

The built‑in microphone captures sound without extra wiring, while the speaker header lets you attach a small speaker directly. Together they turn the module into a self‑contained listening and speaking device for robotics, smart assistants or interactive installations. No separate audio HAT or codec board is required.

Sampling Rates From 8K To 48K Hz

Supported rates include 8K, 11.025K, 12K, 16K, 22.05K, 24K, 32K, 44.1K and the default 48K Hz, covering voice commands through to CD‑quality playback. The single USB channel limits simultaneous multi‑channel recording, so projects needing surround capture or professional‑grade dynamic range will need a dedicated audio interface.

Points forts

  • Driver-free USB 2.0 audio for instant Raspberry Pi and Jetson Nano setup
  • Onboard microphone plus speaker header enables recording and playback in one module
  • Stereo codec supports sampling rates from 8K up to 48K Hz
  • Works with Windows 7 through 10, Mac OS, Linux, Android and WinCE
  • Compact plug-and-play design adds sound without extra drivers or power

Caractéristiques

BrandLORDWORLD

Questions sur cet article

Will the onboard microphone need replacing after extended use?

The onboard microphone is soldered to the board and not user-replaceable; if it fails the whole module would need to be swapped.

What sampling-rate ceiling limits continuous recording quality?

The highest supported rate is 48 kHz, so sustained captures cannot exceed that resolution.

How much heat or noise does the board produce when running all day?

The module draws power only from the USB 2.0 port, has no fan or moving parts, and runs silently with negligible heat.
