MAXSUN
MAXSUN GeForce RTX 4060 iCraft OC 8G graphics card
Mid-range graphics card with 8 GB GDDR6 on a 128-bit bus, 3072 CUDA cores, Ada Lovelace architecture, DLSS 3.5 ray tracing, triple-fan cooling, and 115 W TDP
- InterfacePCI Express 4.0 x8
- Chipset ManufacturerNVIDIA
- GPU SeriesNVIDIA GeForce RTX 40 Series
- GPUGeForce RTX 4060
- ArchitectureAda Lovelace
- Core Clock1830 MHz
- Ada Lovelace architecture enables DLSS 3.5 and ray tracing
- Boost clock reaches 2550 MHz for responsive 1080p gaming
- 8 GB GDDR6 at 17 Gbps delivers 272 GB/s bandwidth
- M-Flow triple-fan cooler with ceramic coating keeps thermals in check
- HDMI 2.1a and three DisplayPort 1.4a outputs drive 4K 240 Hz or 8K 60 Hz
Built for 1080p and 1440p gaming
The MAXSUN GeForce RTX 4060 iCraft OC 8G targets players who want modern Ada Lovelace features at a mainstream price. It carries 3072 CUDA cores and 8GB of GDDR6 memory across a 128-bit bus. A factory boost clock of 2550 MHz and 17 Gbps memory speed deliver 272 GB/s bandwidth for smooth frame rates.
PCIe 4.0 x8 and display outputs
The card uses a PCI Express 4.0 x8 interface, which runs at full speed on 4.0 platforms and negotiates to 3.0 on older boards. One HDMI 2.1 port and three DisplayPort 1.4a connectors support up to four monitors. Digital resolution reaches 7680 x 4320 at 60 Hz or 4K at 240 Hz for high-refresh panels.
115 W TDP and 550 W PSU recommendation
Power draw is rated at 115 W TDP, so a 550 W supply is the recommended minimum. The triple-fan M-Flow cooler with ceramic coating handles that heat load in a 317 x 132 x 46 mm frame. One-press RGB control cycles through breathing, ice blue, ice white and off modes.
Points forts
- Ada Lovelace architecture enables DLSS 3.5 and ray tracing
- Boost clock reaches 2550 MHz for responsive 1080p gaming
- 8 GB GDDR6 at 17 Gbps delivers 272 GB/s bandwidth
- M-Flow triple-fan cooler with ceramic coating keeps thermals in check
- HDMI 2.1a and three DisplayPort 1.4a outputs drive 4K 240 Hz or 8K 60 Hz
Caractéristiques
| Brand | MAXSUN |
|---|---|
| Series | iCraft |
| Model | MS-GeForce RTX 4060 |
| Interface | PCI Express 4.0 x8 |
| Chipset Manufacturer | NVIDIA |
| GPU Series | NVIDIA GeForce RTX 40 Series |
| GPU | GeForce RTX 4060 |
| Architecture | Ada Lovelace |
| Core Clock | 1830 MHz |
| Boost Clock | 2550 MHz |
| CUDA Cores | 3072 |
| Effective Memory Clock | 17000 MHz (17 Gbps) |
| Memory Size | 8GB |
| Memory Interface | 128-Bit |
| Memory Type | GDDR6 |
| DirectX | DirectX 12 |
| OpenGL | OpenGL 4.6 |
| Multi-Monitor Support | 4 |
| HDMI | 1 x HDMI |
| DisplayPort | 3 x DisplayPort |
| Max Resolution | 7680 x 4320 |
| 3D VISION Game Ready | Yes |
| Virtual Reality Ready | Yes |
| Cooler | Triple Fans |
| Operating Systems Supported | Windows11,Windows10 |
| Thermal Design Power | 115W |
| Recommended PSU Wattage | 550W |
| Power Connector | 8-Pin |
| HDCP Ready | Yes |
| Features | Ray Tracing Cores(2nd Generation), Tensor Cores(3rd Generation), Microsoft DirectX 12 Ultimate, NVIDIA DLSS, NVIDIA Reflex, NVIDIA Broadcast, PCI Express Gen 4, Resizable BAR, NVIDIA GeForce Experience, NVIDIA Ansel, NVIDIA FreeStyle, NVIDIA ShadowPlay, NVIDIA Highlights, NVIDIA G-SYNC, Game Ready Drivers, NVIDIA Studio Drivers, NVIDIA GPU Boost, NVIDIA NVLink (SLI-Ready), Vulkan RT API, OpenGL 4.6, HDMI 2.1, DisplayPort 1.4a NVIDIA Encoder(7th Generation), NVIDIA Decoder(5th Generation), VR Ready, Simultaneous Multi-ProjectionVR, VRWorks Audio, HDCP2.3, PureVideo HD, PhysX, PureVide |
| Form Factor | ATX |
| Max GPU Length | 317 mm |
| Card Dimensions (L x H) | 317*46 mm |
Questions sur cet article
Should I choose the iCraft OC 8G or another 4060 with more memory?
This model is offered only in an 8 GB GDDR6 configuration with a 128-bit bus, so there is no larger frame-buffer variant of the iCraft OC to pick from.
What does the 2550 MHz boost clock deliver in actual games?
The 2550 MHz boost clock is the peak frequency the GPU can reach under load; real-world frame rates will depend on the title, resolution and DLSS 3.5 settings you choose.
What does the PCIe 4.0 x8 interface mean for bandwidth?
The card uses a PCIe 4.0 x8 link, providing the standard lane width for the RTX 4060 and matching the 115 W TDP design target.
