Rectangular metal power supply unit with built-in fan and AC voltage selector switch

Mean Well

Mean Well PB-360N-12 14.7V 24.3A Battery Charger Power Supply

SKU CH-04JZ-PJ9DE

Charges lead-acid batteries at 14.7V 24.3A with three-stage charging, selectable 115/230VAC input and passive PFC

  • TypeAT
  • Three-stage charging optimises lead-acid battery life
  • Selectable 115/230 VAC input suits global mains supplies
  • Built-in passive PFC meets EN61000-3-2 Class A
  • Comprehensive protection covers short circuit, reverse polarity, over-voltage and over-temperature
  • Fan runs only when charging current demands cooling

Lead-acid battery charger

The Mean Well PB-360N-12 is a single-output power supply designed to charge lead-acid batteries using a three-stage charging profile. It delivers 14.7V at up to 24.3A for use in backup power, industrial equipment or off-grid installations. The unit operates from AC mains selected by a 115/230VAC switch.

Input voltage selection and PFC

The charger accepts either 115VAC or 230VAC input set by a manual switch, so the installer must match the local mains voltage before connection. An optional built-in passive PFC function complies with EN61000-3-2 Class A for harmonic current limits. No active power factor correction is included.

Protection features and cooling

Built-in protections cover short circuit, reverse polarity, over voltage and over temperature conditions. A two-colour LED indicator shows the charging status at a glance. The fan runs only when charging current demands it, reducing noise during low-load periods. The AT form factor suits standard industrial mounting.

Points forts

  • Three-stage charging optimises lead-acid battery life
  • Selectable 115/230 VAC input suits global mains supplies
  • Built-in passive PFC meets EN61000-3-2 Class A
  • Comprehensive protection covers short circuit, reverse polarity, over-voltage and over-temperature
  • Fan runs only when charging current demands cooling

Caractéristiques

TypeAT

Questions sur cet article

Which output voltage should I pick for a 12 V lead-acid bank?

The unit delivers 14.7 V, which is the correct absorption voltage for a nominal 12 V lead-acid battery.

What does the 360 W rating mean when the charger is connected to a battery?

At 14.7 V the supply can provide up to 24.3 A, giving roughly 360 W of charging power.

How does the AC input selector affect the PFC compliance?

The passive PFC meets EN61000-3-2 Class A whether the switch is set to 115 VAC or 230 VAC.
