Rectangular metal power supply unit with built-in cooling fan

Mean Well

Mean Well QP-200F Quad Output Power Supply 200W

SKU CH-HCAW-KGTSH

Quad-output AT power supply delivering 200 W across 5 V, 15 V, 24 V and -15 V rails with active PFC and forced-air cooling

  • TypeAT
  • Quad outputs power diverse components from one unit
  • Active PFC improves power efficiency across full input range
  • Built-in DC fan maintains stable temperatures under load
  • Comprehensive protections guard against short circuit and overvoltage
  • 100% burn-in tested for reliable operation out of the box

Industrial quad-output power supply

The Mean Well QP-200F delivers four regulated rails at five volts, fifteen volts, twenty-four volts and minus fifteen volts from a single two-hundred-watt unit. It suits test benches, automation cabinets and legacy AT chassis that need multiple voltages simultaneously.

Check your AT-form-factor clearance

Verify the chassis accepts an AT-style supply and that the mounting pattern matches your frame. The unit operates on universal AC input, so confirm your local mains voltage falls within the full-range specification before wiring.

Forced-air cooling requires unrestricted intake

A built-in DC fan handles thermal loads at one-hundred-fifty watts and above, so leave space around the ventilation openings. The active PFC function eases harmonic distortion on shared mains circuits, while short-circuit, overload, over-voltage and over-temperature protections guard connected equipment.

Points forts

  • Quad outputs power diverse components from one unit
  • Active PFC improves power efficiency across full input range
  • Built-in DC fan maintains stable temperatures under load
  • Comprehensive protections guard against short circuit and overvoltage
  • 100% burn-in tested for reliable operation out of the box

Caractéristiques

TypeAT

Questions sur cet article

What comes with the Mean Well QP-200F and what must be sourced separately?

The unit ships as a bare power supply with built-in active PFC and a DC fan for forced-air cooling. You will need to supply an AC mains cord, mounting hardware and any output cables or connectors required by your equipment.

The title lists four rails at 5 V, 15 V, 24 V and -15 V — how do I decide which capacity to order?

This model is a single 200 W quad-output unit delivering 15 A on 5 V, 3 A on 15 V, 3 A on 24 V and 0.9 A on -15 V. There are no alternative capacities for this part number; choose it only if those combined rails meet your load requirements.

What does the 200 W rating mean once the supply is installed in a real system?

It indicates the maximum continuous power the four rails can deliver together when cooled by the internal fan, with protections for short circuit, overload, over-voltage and over-temperature active during operation.
