Compact black mini PC barebone with front ports and dual-fan cooling visible

minisforum

minisforum MS-A2 Ryzen 9 9955HX barebone mini PC

SKU CH-XBT2-4810J

Barebone mini workstation with a 16-core Ryzen 9 9955HX, dual 10 Gbps SFP+ and dual 2.5 Gbps LAN, plus triple 8K video output

  • ColorBlack
  • CPU TypeAMD Ryzen 9 9955HX
  • CPU SocketFL1
  • CPU Cores16
  • Memory installedNo Memory
  • Memory slot2

Option MSA2-9955 · 0+0

  • 16-core Ryzen 9 9955HX reaches 5.4 GHz for heavy workloads
  • AMD Radeon 610M integrated graphics at 2.2 GHz handles visual tasks
  • Triple 8K output via HDMI and two USB-C ports drives three displays
  • Dual 10 Gbps SFP+ plus two 2.5 Gbps RJ45 ports for fast networking
  • Two DDR5-5600 slots accept up to 96 GB memory

Ready-to-build mini workstation

The minisforum MS-A2 is a barebone mini PC built around an AMD Ryzen 9 9955HX processor with 16 cores and 32 threads reaching up to 5.4 GHz. It ships without memory, storage or an operating system so integrators can choose their own DDR5-5600 modules up to 96 GB across two slots.

Suited for high-speed network appliances

This unit fits builders who need dual 10 Gbps SFP+ ports and dual 2.5 Gbps RJ45 ports in a compact chassis for storage servers, routers or virtualisation hosts. It is not for buyers who require discrete graphics power or a pre-installed operating system.

Triple 8K video output

One HDMI port and two USB-C ports with DisplayPort Alt Mode each drive an 8K display at 60 Hz, enabling three simultaneous high-resolution screens for signage, trading desks or CAD workstations.

Points forts

  • 16-core Ryzen 9 9955HX reaches 5.4 GHz for heavy workloads
  • AMD Radeon 610M integrated graphics at 2.2 GHz handles visual tasks
  • Triple 8K output via HDMI and two USB-C ports drives three displays
  • Dual 10 Gbps SFP+ plus two 2.5 Gbps RJ45 ports for fast networking
  • Two DDR5-5600 slots accept up to 96 GB memory

Caractéristiques

BrandMINISFORUM
ModelDeskMini
ColorBlack
CPU TypeAMD Ryzen 9 9955HX
CPU SocketFL1
CPU Cores16
Memory installedNo Memory
Memory slot2
Memory Type SupportedDDR5 5600
Max Memory Supported96GB
Dual Channel Memory SupportedYes
Other3x PCIe4.0x4
Integrated GraphicsAMD Radeon 610M
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6E
BluetoothBluetooth 5.2
Front USB3
HDMI1
Rear USB2
RJ452
Power Supply19V/12.63A 240W

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Does the MS-A2 barebone include RAM and storage, or must I buy them separately?

The unit ships with no memory and no drive installed; you add two DDR5 5600 SODIMM modules up to 96 GB total and an M.2 2280 PCIe 4.0 SSD yourself.

Which DDR5 speed should I choose for the Ryzen 9 9955HX — 5200 MT/s or 5600 MT/s?

The board is rated for DDR5 5600, so 5600 MT/s modules run at their rated speed; 5200 MT/s modules will work but operate at the lower frequency.

What does the 5.4 GHz boost clock mean for daily workloads on this 16-core CPU?

The 16-core Ryzen 9 9955HX can reach 5.4 GHz on lightly threaded tasks, while sustained multi-core speeds will be lower depending on the dual-fan cooling capacity.
