Compact grey metal DIN-rail power supply with four output channels and LED indicators

myVolts

myVolts CENTROPOWER 12V 5A 4-Channel Din-Rail Power Supply

SKU CH-ZGQ1-GJ9WC

A 12V 5A four-channel DIN-rail supply with adjustable per-channel output, PTC fuse protection and 105 °C capacitors for CCTV or LED installations

  • TypeAT
  • Powers four cameras from one 60 W unit
  • Adjustable 11–15 V output per channel for flexible installs
  • Automatic voltage regulation keeps output stable across wide input range
  • Built-in PTC fuse plus over-voltage, under-voltage and short-circuit protection
  • 105 °C-rated electrolytic capacitors rated for –20 to 45 °C operation

CENTROPOWER 12V 5A 4-Channel Power Supply

This DIN-rail unit delivers 12 V at up to 5 A per channel across four independent outputs. It is designed for installers who need a compact distribution point for CCTV cameras or similar low-voltage devices. The 60 W total capacity and adjustable voltage per channel simplify wiring in security and LED installations.

Suits multi-camera sites needing individual

Each channel includes a PTC fuse, overload safeguard and short-circuit protection with LED status indication. Automatic voltage regulation maintains stable output across a wide input range. It is not suited for applications requiring higher per-channel current, more than four outputs, or voltages outside the 11 V to 15 V adjustment window.

Four channels at 5 A each give 60 W headroom

The supply comfortably powers four typical cameras or LED strips with independent voltage tuning. Operating temperature spans -20 °C to 45 °C using 105 °C rated electrolytic capacitors. Headroom diminishes if total draw approaches the 60 W limit or if ambient temperatures exceed the rated maximum.

Points forts

  • Powers four cameras from one 60 W unit
  • Adjustable 11–15 V output per channel for flexible installs
  • Automatic voltage regulation keeps output stable across wide input range
  • Built-in PTC fuse plus over-voltage, under-voltage and short-circuit protection
  • 105 °C-rated electrolytic capacitors rated for –20 to 45 °C operation

Caractéristiques

TypeAT

Questions sur cet article

What input voltage range must my site provide for the CENTROPOWER to operate?

The unit accepts a wide input range of 11 V to 15 V DC, so your existing DC source must stay within those limits.

Can I keep my 12 V cameras and run each on its own channel without rewiring?

Yes, each of the four channels delivers adjustable 12 V output up to 5 A total, letting you power existing cameras independently.

How do I verify all four channels are delivering power after installation?

Each channel has its own LED indicator; when all four LEDs are lit the supply is distributing power as intended.
