Narrow grey plastic DIN-rail power supply unit

myVolts

myVolts HDR-150 150W DIN Rail Power Supply 12V 15V 24V 48V

SKU CH-97CN-6P1HD

150W DIN rail power supply with selectable 12V, 15V, 24V or 48V output and 90.5% efficiency

  • TypeAT
  • 150W output with adjustable 12V, 15V, 24V or 48V DC rails
  • Ultra-slim 105mm width saves cabinet space on TS-35 DIN rails
  • Universal 85-264VAC input meets EN61000-3-2 harmonic current limits
  • Operates from -30°C to 70°C with 90.5% efficiency and convection cooling
  • Plastic housing prevents electric shock; protections include short-circuit, overload and over-voltage

Compact DIN Rail Power Supply

The myVolts HDR-150 is a 150W DIN rail power supply designed for household automation, building control and industrial machinery. It delivers selectable outputs of 12V, 15V, 24V or 48V with currents up to 10.2A, 8.55A, 5.31A and 2.72A respectively. The unit accepts a universal AC input range of 85 to 264VAC with 277VAC operational capability.

Straightforward Rail Mounting

Installation uses standard TS-35/7.5 or TS-35/15 DIN rails and the ultra-slim 105mm width saves cabinet space. Cooling relies on free air convection with no moving parts, and a built-in LED indicates power status. Protections cover short circuit, overload and over voltage, while no-load consumption stays below 0.3W.

For Automation Cabinets, Not PC Builds

This supply suits installers fitting panels for factory automation, electro-mechanical apparatus or home control systems needing a certified, convection-cooled unit. It is not for PC builders requiring ATX connectors, modular cabling or GPU power cables, nor for anyone needing forced-air cooling or redundant hot-swap modules.

Points forts

  • 150W output with adjustable 12V, 15V, 24V or 48V DC rails
  • Ultra-slim 105mm width saves cabinet space on TS-35 DIN rails
  • Universal 85-264VAC input meets EN61000-3-2 harmonic current limits
  • Operates from -30°C to 70°C with 90.5% efficiency and convection cooling
  • Plastic housing prevents electric shock; protections include short-circuit, overload and over-voltage

Caractéristiques

TypeAT

Questions sur cet article

How can I confirm the HDR-150 is working correctly after wiring it to the DIN rail?

The green LED indicator lights up when the unit powers on, showing the output is live.

What comes with the HDR-150 and what must I source separately?

The supply itself is included; you must provide the TS-35/7.5 or TS-35/15 mounting rail and input/output wiring.

Which output voltage version should I choose for my 150 W application?

Select 12 V (10.2 A), 15 V (8.55 A), 24 V (5.31 A) or 48 V (2.72 A) to match your load’s voltage and current needs.
