Black mid-tower ATX case with tempered glass side panel and mesh front and top panels

NZXT

NZXT CC-H52FB-01 H5 Flow 2024 ATX Mid Tower PC Case

SKU CH-TC0V-YD2Y5 MPN CC-H52FB-01

Mid-tower ATX case with perforated PSU shroud, mesh panels, front 360 mm and top 240 mm radiator support, two pre-installed 120 mm fans, USB 3.2 Type-C front port

  • Motherboard CompatibilityATX / E-ATX / Micro ATX / Mini ITX
  • Power Supply MountedBottom
  • ColorBlack
  • Case MaterialSGCC Steel / Dark Tinted Tempered Glass
  • TypeATX Mid Tower
  • With Power SupplyNo

Options H5 Flow (Black)

  • Perforated PSU shroud and mesh panels direct cool air straight to the GPU
  • Ultra-fine mesh doubles as dust filter while maintaining high airflow
  • Front supports 360 mm radiator, top fits 240 mm or 280 mm with low-profile RAM
  • Pre-installed 120 mm fans at front and rear deliver balanced airflow out of the box
  • Wide cable channels, hooks and straps keep routing clean and organised

H5 Flow 2024 ATX Mid Tower

The NZXT H5 Flow 2024 Edition is a compact ATX mid-tower chassis built for builders who want strong airflow and GPU cooling in a clean black design. It fits ATX, E-ATX, Micro ATX and Mini ITX motherboards and includes two pre-installed 120 mm Quiet Airflow fans at the front and rear.

Perforated shroud and mesh panel airflow limits

A fully perforated PSU shroud and ultra-fine mesh panels draw cool air from the bottom and front directly toward the graphics card. The top panel accepts radiators up to 240 mm, or 280 mm only when low-profile memory is used, while the front supports up to 360 mm for larger liquid-cooling loops.

410 mm maximum graphics card length

The case clears graphics cards up to 410 mm long, which determines whether a specific model will fit without modification. Seven expansion slots, one 3.5-inch bay and two 2.5-inch bays complete the internal layout for storage and add-in cards.

Points forts

  • Perforated PSU shroud and mesh panels direct cool air straight to the GPU
  • Ultra-fine mesh doubles as dust filter while maintaining high airflow
  • Front supports 360 mm radiator, top fits 240 mm or 280 mm with low-profile RAM
  • Pre-installed 120 mm fans at front and rear deliver balanced airflow out of the box
  • Wide cable channels, hooks and straps keep routing clean and organised

Caractéristiques

Motherboard CompatibilityATX / E-ATX / Micro ATX / Mini ITX
Power Supply MountedBottom
ColorBlack
Case MaterialSGCC Steel / Dark Tinted Tempered Glass
TypeATX Mid Tower
With Power SupplyNo
Side Panel1 x Side Tempered Glass Panel
Dust FiltersBottom / Front / Top
Front Ports1 x USB 3.2 Type-A, 1 x USB 3.2 Type-C, 1 x Audio
BrandNZXT
SeriesH5 Flow
ModelCC-H52FB-01
Part NumberCC-H52FB-01
Internal 3.5" Drive Bays1
Internal 2.5" Drive Bays2
Expansion Slots7
Fan OptionsFront: 3 x 120 mm / 2 x 140 mm (1 x F120Q Case Version included)
Top: 2 x 120 mm / 2 x 140 mm
Bottom: 2 x 120 mm
Rear: 1 x 120 mm (1 x F120Q Case Version included)
Pre-installed FansFront - 1 x 120mm / Rear - 1 x 120mm
Radiator OptionsFront: Up to 360 mm
Top: Up to 240 mm (280mm with low-profile memory only)
Max GPU Length410 mm
Max CPU Cooler Height170 mm
Max PSU Length200 mm
Dimensions465 x 225 x 430 mm / 18.31" x 8.86" x 16.93"
Weight7.28 kg / 16.04 lbs.
FeaturesThe H5 Flow boosts airflow and GPU cooling with its fully-perforated PSU shroud, mesh panels, and robust radiator support—all in a compact mid-tower form factor.
Package Content1 x H5 Flow
2 x F120Q (CV)
1 x Installation accessories
1 x User guide
Poids d’expédition9.57 kg
Dimensions du colis559 × 523 × 315 mm

Autres versions de ce modèle

3 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Should I pick the 2024 edition or an older H5 Flow?

The 2024 edition ships with two pre-installed 120 mm F120Q fans at front and rear, a perforated PSU shroud for bottom intake, and ultra-fine mesh panels that double as dust filters.

What does the 410 mm GPU length mean for my graphics card choice?

It fits most triple-slot cards up to 410 mm, leaving room for a front 360 mm radiator or three 120 mm fans without clearance conflicts.

How does the USB 3.2 Type-C front port perform in daily use?

The single USB 3.2 Gen 1 Type-C port delivers up to 5 Gbps and connects to a motherboard header, so speed depends on the board's controller and cable quality.
