partaker C6 Fanless Mini PC Celeron J6412 4GB DDR4 128GB M.2 3×2.5GbE
Fanless mini desktop with a Celeron J6412, 4 GB DDR4, 128 GB M.2 storage and three 2.5 GbE ports for router or edge workloads
- TypeBusiness Desktops & Workstations
- ColorBlack
- MonitorMonitor not included
- Operating SystemWindows 10 Pro
- Windows 11Ready
- CPU TypeCeleron
- Fanless aluminium chassis runs silently in noise-sensitive sites
- Intel Celeron J6412 quad-core 2.0 GHz handles routing and edge workloads
- Three Intel I225-V 2.5 GbE ports give high-throughput multi-WAN connectivity
- 4 GB DDR4 3200 MHz and 128 GB M.2 2280 SSD provide responsive OS and log storage
- Dual DP and HDMI drive two 4K 60 Hz displays for signage or monitoring
Purpose-built Network Appliance
The Partaker C6 is a fanless mini desktop that ships with Windows 10 Pro and Windows 11 ready. Its Celeron J6412 quad-core processor runs at 2.0 GHz and includes AES-NI acceleration plus TPM 2.0 encryption. Three Intel I225-V 2.5 GbE ports make it suited for firewall, router or edge-gateway roles in commercial and industrial settings.
Build Integration
The aluminium chassis measures 150 x 126.5 x 45 mm and weighs 1 to 1.5 kg, mounting easily in tight enclosures or behind displays. A 120 x 120 mm mini-ITX board provides one DDR4 3200 MHz SODIMM slot (occupied by 4 GB, max 32 GB), one M.2 2280 M-key slot with SATA protocol (populated with 128 GB), one 2.5 inch drive bay, one M.2 3052 B-key slot with SIM for 4G/5G, and one M.2 2230 E-key slot for wireless. Video outputs comprise two DisplayPort and one HDMI, each capable of 4K 60 Hz.
Thermals & Power
Passive cooling through the aluminium shell enables silent operation from 0 to 40 °C with commercial drives or -20 to 60 °C with industrial SSDs. Humidity tolerance spans 0 to 95 % non-condensing. The platform supports auto power-on, timed boot, Wake-on-LAN, PXE boot and a 0-255 level watchdog for unattended reliability.
Points forts
- Fanless aluminium chassis runs silently in noise-sensitive sites
- Intel Celeron J6412 quad-core 2.0 GHz handles routing and edge workloads
- Three Intel I225-V 2.5 GbE ports give high-throughput multi-WAN connectivity
- 4 GB DDR4 3200 MHz and 128 GB M.2 2280 SSD provide responsive OS and log storage
- Dual DP and HDMI drive two 4K 60 Hz displays for signage or monitoring
Caractéristiques
| Type | Business Desktops & Workstations |
|---|---|
| Color | Black |
| Monitor | Monitor not included |
| Operating System | Windows 10 Pro |
| Windows 11 | Ready |
| CPU Type | Celeron |
| CPU Name | 2.00GHz |
| GPU/VGA Type | Intel UHD Graphics |
| Memory Capacity | 4GB DDR4 |
| HDD | No |
| Screen Size | No Screen |
Questions sur cet article
What is the maximum operating temperature for sustained use with the included SSD?
The system is rated for 0 to +40 °C with a commercial drive and -20 to +60 °C with an industrial SSD, so the limit depends on which storage type is installed.
How much heat does the fanless aluminium chassis dissipate during continuous 2.5 GbE throughput?
The pure-aluminium enclosure acts as a passive heatsink; with three Intel I225-V ports at full load the CPU stays within its thermal envelope without active cooling.
Which display cables must the buyer already have to use the video outputs?
The unit provides two DisplayPort and one HDMI connector, all supporting 4K at 60 Hz, so cables with matching plugs are required.
