Compact grey industrial desktop, fan-cooled aluminium case, Phoenix power terminal, multiple ports visible

partaker

partaker I14 i7-10700T 16GB 256GB desktop PC

SKU CH-99PD-WEGFH

Industrial desktop with Intel Core i7-10700T, 16GB DDR4, 256GB SSD, Windows 11 Pro, three 2.5G LAN ports, six COM ports, 12-24V Phoenix terminal, and fan cooling

  • TypeIndustrial Computer
  • ColorGray
  • MonitorMonitor not included
  • Operating SystemWindows 11 Pro
  • Windows 11Ready
  • CPU TypeIntel Core i7 10th Gen

Memory Capacity 16GB DDR4

SSD 256GB

HDD None

  • Intel Core i7-10700T delivers 8-core performance for industrial workloads
  • 16 GB DDR4 memory handles data-intensive tasks with room to expand to 64 GB
  • 256 GB SSD provides fast boot and application load times
  • Three Intel 2.5G LAN ports ensure high-speed, reliable network connectivity
  • 12-24 V Phoenix terminal accepts wide-range DC input for flexible deployment

Industrial desktop with i7-10700T

The Partaker I14 is a fan-cooled industrial desktop powered by an Intel Core i7-10700T processor. It ships with 16GB DDR4 memory and a 256GB SSD, running Windows 11 Pro. The aluminium and sheet-metal chassis measures 225 x 240 x 83mm and weighs 2.80 kgs, designed for DIN-rail or wall mounting in control cabinets.

Upgrade from legacy IPCs

This unit replaces older fanless boxes that max out at 4GB or 8GB RAM and single gigabit LAN. The jump is worth it when an application needs 2.5G Ethernet throughput, six COM ports with RS232/485 flexibility, or the headroom of two SODIMM slots supporting up to 64GB DDR4. Builders who need more than two 2.5-inch drive bays or a PCIe x16 slot for add-in cards should look elsewhere.

Interface and power limits

Three Intel I225-V 2.5G LAN ports share the platform's PCIe lanes, so simultaneous line-rate traffic on all three may contend with M.2 NVME or 4G/5G modules. The 12-24V Phoenix terminal accepts wide-voltage DC input; the 60-100W TDP range means the supply must deliver adequate current across the full voltage span. Operating temperature is rated 0°C to 50°C with commercial SSD and -20°C to 60°C with industrial SSD.

Points forts

  • Intel Core i7-10700T delivers 8-core performance for industrial workloads
  • 16 GB DDR4 memory handles data-intensive tasks with room to expand to 64 GB
  • 256 GB SSD provides fast boot and application load times
  • Three Intel 2.5G LAN ports ensure high-speed, reliable network connectivity
  • 12-24 V Phoenix terminal accepts wide-range DC input for flexible deployment

Caractéristiques

TypeIndustrial Computer
ColorGray
MonitorMonitor not included
Operating SystemWindows 11 Pro
Windows 11Ready
CPU TypeIntel Core i7 10th Gen
CPU NameIntel Core i7-10700T
Memory Capacity16GB DDR4
SSD256GB
HDDNo
Screen SizeNo Screen

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What are the exact dimensions and mounting weight of the Partaker I14 chassis?

The chassis measures 225 x 240 x 83 mm and weighs 2.80 kg, allowing it to fit on a standard DIN rail or wall bracket rated for at least 3 kg.

Which BIOS setting must be enabled before the 12-24 V Phoenix terminal will power the unit?

In the AMI EFI BIOS, enable "Auto Power On" under the Advanced Power menu; otherwise the system stays off when DC voltage is applied to the 4-pin Phoenix connector.

How often should the internal cooling fan be cleaned in a dusty factory running at 50 °C ambient?

Inspect and blow out the fan every three months; the fan is the only active cooling component and its airflow path clogs quickly above 40 °C.
