Silver 3U rackmount chassis with sixteen front drive bays and dual power supplies

Qnap

Qnap TS-1673AU-RP-16G-US 16-bay rackmount NAS

SKU CH-1WYT-PG66M MPN TS-1673AU-RP-16G-US

A 16-bay rackmount NAS with AMD Ryzen V1500B processor, 16GB DDR4 memory, dual 2.5 GbE ports, redundant 550W power supplies, and PCIe expansion slots for 10GbE or NVMe upgrades

  • Port RJ-452 x 2.5 GbE
  • HDD Interface16 x SATA (16 x Bay)
  • Form Factor16-Bay
  • ProcessorAMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor
  • Installed Memory16GB
  • Max Memory Capacity64GB
  • AMD Ryzen V1500B 4-core processor powers demanding workloads
  • 16 drive bays support up to 352TB raw capacity
  • Dual 2.5GbE ports enable aggregated 5Gbps throughput
  • Redundant 550W power supplies maximise system uptime
  • Two PCIe 3.0 x4 slots allow 10GbE or NVMe expansion

16-Bay AMD Ryzen NAS

The Qnap TS-1673AU-RP-16G-US is a 3U rackmount storage server built around an AMD Ryzen V1500B quad-core processor running at 2.2 GHz. It ships with 16 GB of DDR4 memory, expandable to 64 GB across two SODIMM slots. Sixteen SATA drive bays support 3.5-inch hard drives or 2.5-inch SSDs for a maximum raw capacity of 352 TB. Dual redundant 550 W power supplies and two 2.5 GbE RJ-45 ports come standard.

Suits virtualisation and heavy multi-user workloads

Two PCIe 3.0 x4 slots allow the addition of 10 GbE adapters, M.2 NVMe caching cards or entry-level NVIDIA GPUs for video processing and GPU passthrough. Qtier auto-tiering and SSD caching keep hot data on fast media. Organisations needing only basic file sharing or a smaller bay count will find the 16-bay chassis and redundant power unnecessary.

Deciding spec: sixteen SATA bays

The combination of sixteen hot-swappable SATA bays and dual 550 W power supplies determines whether this unit fits the rack space, drive count and uptime requirements of the deployment.

Points forts

  • AMD Ryzen V1500B 4-core processor powers demanding workloads
  • 16 drive bays support up to 352TB raw capacity
  • Dual 2.5GbE ports enable aggregated 5Gbps throughput
  • Redundant 550W power supplies maximise system uptime
  • Two PCIe 3.0 x4 slots allow 10GbE or NVMe expansion

Caractéristiques

BrandQNAP
Part NumberTS-1673AU-RP-16G-US
Port RJ-452 x 2.5 GbE
HDD Interface16 x SATA (16 x Bay)
Form Factor16-Bay
ProcessorAMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor
Installed Memory16GB
Max Memory Capacity64GB
Memory Slot2 x DDR4 SODIMM
Included HDD CapacityDiskless System
Max Capacity352TB
Drive Compatibility3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
LEDsHDD 1-16, Status, LAN, USB, Power
Power550W (x2), 100-240V AC, 50-60Hz, 7-3.5A
Power ConsumptionPower Consumption: HDD Sleep Mode 47.75 W
Power Consumption: Operating Mode, Typical 97.34 W
UsageUltra high prerformance for large number of users
TemperatureOperating Temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Humidity5-95% RH non-condensing, wet bulb: 27°C (80.6°F)
Dimensions5.2 × 18.98 × 16.73 inch
WeightWeight (Net) 26.46 lbs
Weight (Gross) 37.81 lbs
Poids d’expédition15.85 kg
Dimensions du colis597 × 594 × 305 mm

Questions sur cet article

How loud and hot does the TS-1673AU-RP get when it runs 24/7 with sixteen drives spinning?

The unit draws 97.34 W in typical operation and drops to 47.75 W when the drives sleep. It is rated for 0 – 40 °C ambient temperature and 5 – 95 % non-condensing humidity, so a normal server rack with standard airflow keeps it within spec.

Which drives and memory modules must I supply myself because the chassis ships empty?

You need sixteen 3.5-inch SATA hard drives or 2.5-inch SATA SSDs for the bays, plus up to two DDR4 SODIMM sticks if you want to expand beyond the installed 16 GB up to the 64 GB maximum.

Will my existing 1 GbE switches and older SATA drives work without extra adapters?

Yes. Both 2.5 GbE ports auto-negotiate down to 1 GbE, 100 MbE or 10 MbE, and the sixteen drive bays accept any 3.5-inch or 2.5-inch SATA drive you already own.
