Compact two-bay desktop NAS in matte black finish

Qnap

Qnap TS-264-8G-US NAS 2-Bay Intel Celeron N5095 8GB DDR4 2 x 2.5GbE

SKU CH-2XER-0DZH2 MPN TS-264-8G-US

Two-bay desktop NAS with Intel Celeron N5095 processor, 8 GB DDR4, and dual 2.5 GbE ports for fast file sharing

  • TypeDesktop NAS
  • Ports1 x Expansion Port / 1 x HDMI 2.0 / 2 x 2.5GbE / 2 x USB 2.0
  • Port RJ-452 x 2.5 GbE
  • HDD Interface2 x SATA (2 x Bay)
  • Form Factor2-Bay
  • ProcessorIntel Celeron N5095
  • Intel 4-core processor bursts to 2.9 GHz for responsive multi-tasking
  • 8 GB DDR4 memory handles simultaneous apps and virtual machines
  • Two 2.5 GbE ports deliver up to 2.5 Gbps network throughput
  • Two M.2 2280 slots plus PCIe Gen3 x2 slot add cache or extra connectivity
  • Diskless 2-bay chassis accepts 3.5" or 2.5" SATA drives up to 16 TB total

Two-bay desktop NAS for small teams

The TS-264-8G-US is a diskless desktop NAS with two drive bays, an Intel Celeron N5095 four-core processor that bursts to 2.9 GHz and 8 GB of onboard DDR4 memory. It targets home offices and small businesses that need shared storage, backup and light virtualisation without a rackmount chassis.

Thermals noise and power draw

Typical operating power is 29.086 W with drives installed and drops to 18.288 W in HDD sleep mode, supplied by a 65 W adapter rated for 100-240 V input. The unit is rated for 0-40 °C operating temperature and 5-95 % relative humidity non-condensing.

Expansion slots and connectivity

Two M.2 2280 PCIe Gen 3 x1 slots and one PCIe Gen 3 x2 slot allow adding cache or extra network cards. Front and rear ports include two 2.5GbE RJ-45, one HDMI 2.0, two USB 2.0 and two USB 3.2 Gen 2 for direct-attached storage or peripherals.

Points forts

  • Intel 4-core processor bursts to 2.9 GHz for responsive multi-tasking
  • 8 GB DDR4 memory handles simultaneous apps and virtual machines
  • Two 2.5 GbE ports deliver up to 2.5 Gbps network throughput
  • Two M.2 2280 slots plus PCIe Gen3 x2 slot add cache or extra connectivity
  • Diskless 2-bay chassis accepts 3.5" or 2.5" SATA drives up to 16 TB total

Caractéristiques

BrandQNAP
SeriesTS-264 2-Bay
ModelTS-264
Part NumberTS-264-8G-US
TypeDesktop NAS
Ports1 x Expansion Port / 1 x HDMI 2.0 / 2 x 2.5GbE / 2 x USB 2.0 / 2 x USB 3.2 Gen 2
Port RJ-452 x 2.5 GbE
HDD Interface2 x SATA (2 x Bay)
Form Factor2-Bay
ProcessorIntel Celeron N5095
Installed Memory8GB
Max Memory Capacity8GB
Included HDD CapacityDiskless System
Max Capacity16TB
Drive Compatibility3.5" SATA HDD
2.5" SATA SSD
LEDsPower/Status, LAN, USB, HDD1-2
Power65W adapter, 100-240V
Power ConsumptionHDD Sleep Mode: 18.288 W
Operating Mode: Typical 29.086 W
Tested with drives fully populated.
TemperatureOperating Temperature: 0 - 40 °C (32°F - 104°F)
Storage Temperature: -20 - 70°C (-4°F - 158°F)
Humidity5-95% RH non-condensing, wet bulb: 27°C (80.6°F)
UsageBackup & stream media through personal cloud
Dimensions6.61 × 4.13 × 8.9 inch
WeightWeight (Net): 3.42 lbs
Weight (Gross): 5.91 lbs
Poids d’expédition2.59 kg
Dimensions du colis295 × 277 × 203 mm

Questions sur cet article

How do I install the 3.5" SATA drives in the two bays, and what step is often missed?

Slide each drive into a bay until the SATA connector seats firmly; the step people miss is securing the drive with the supplied screws so vibration does not loosen the connection.

What maintenance or replacement will the 8 GB on-board DDR4 memory need later?

The 8 GB DDR4 is soldered on-board and cannot be upgraded or replaced; no memory maintenance is required beyond keeping the NAS within the 0–40 °C operating range.

Which limit appears first when the Intel Celeron N5095 runs sustained workloads at 2.9 GHz burst?

The processor thermal ceiling is reached before the 65 W adapter limit, causing the CPU to throttle below burst speed to stay within the 40 °C maximum operating temperature.
