Green 288-pin DDR4 DIMM with black chips and silver heat spreader

SK hynix

SK hynix HMA84GR7AFR4N-UH 32GB DDR4 2400 ECC REG DIMM 2Rx4

SKU CH-H7SP-JSRB0

32 GB DDR4 2400 registered ECC DIMM with 2Rx4 organisation for server workloads

  • Capacity32GB
  • Type288-Pin DDR4 SDRAM
  • SpeedDDR4 2400 (PC4 19200)
  • Voltage1.20V
  • ECCYes
  • Buffered/RegisteredRegistered
  • 32 GB capacity supports large server workloads
  • DDR4 2400 speed delivers 19200 MB/s bandwidth
  • ECC registered design corrects errors for reliability
  • 2Rx4 dual-rank organisation improves memory density
  • 20 V operation reduces power consumption

Capacity and rank

This module delivers 32 GB of DDR4 memory in a dual-rank 2Rx4 layout. The density suits virtualisation hosts and database nodes that need large addressable space per DIMM slot. Workloads that exceed the per-module capacity will require additional populated slots.

Speed and voltage

Rated at DDR4 2400 (PC4 19200), the stick runs at 1.20 V standard voltage. Throughput is adequate for mainstream server tasks but becomes a bottleneck in memory-bound HPC or high-frequency trading workloads. Latency scales with the rated frequency and cannot be improved without platform overclocking support.

Registered ECC integration

The registered buffer and on-die ECC reduce electrical load on the memory controller and correct single-bit errors. A compatible server board with registered DIMM support is mandatory; unbuffered consumer platforms will not accept this module. The 288-pin form factor fits standard DDR4 DIMM slots in qualified Supermicro and other vendor systems.

Points forts

  • 32 GB capacity supports large server workloads
  • DDR4 2400 speed delivers 19200 MB/s bandwidth
  • ECC registered design corrects errors for reliability
  • 2Rx4 dual-rank organisation improves memory density
  • 20 V operation reduces power consumption

Caractéristiques

BrandSuperMicro
ModelHMA84GR7AFR4N-UH
Capacity32GB
Type288-Pin DDR4 SDRAM
SpeedDDR4 2400 (PC4 19200)
Voltage1.20V
ECCYes
Buffered/RegisteredRegistered
Rank2Rx4

Questions sur cet article

Will this 288-pin DDR4 2400 ECC registered DIMM run with older DDR4 modules I already have?

The module operates at DDR4 2400 speed; mixing speeds is handled by the platform and may run all modules at the lowest common rate.

How can I confirm the 32 GB 2Rx4 registered ECC module is detected correctly after installation?

Check the server BIOS or OS memory report for 32 GB total, ECC enabled, registered mode active and the correct 2400 MT/s data rate.

Does the box contain only the HMA84GR7AFR4N-UH 32 GB DDR4 2400 ECC REG DIMM or are extra parts included?

The package includes the single 288-pin DIMM; no cables, brackets or additional components are supplied.
