Silver 2.5 inch U.2 enterprise SSD with 15mm thickness

Solidigm

Solidigm SSDPF2KE128T1N1 12.8TB U.2 15mm enterprise SSD

SKU CH-KPTB-QF786 MPN SSDPF2KE128T1N1

Enterprise U.2 15mm SSD delivering 12.8TB capacity with PCIe 4.0 x4 NVMe interface and up to 7100 MB/s sequential read

  • Form FactorU.2 15mm
  • Capacity12.8TB
  • Memory Components144L TLC 3D NAND
  • InterfaceNVMe; PCI Express 4.0 x4
  • Max Sequential ReadUp to 7100 MBps
  • Max Sequential WriteUp to 4300 MBps

Options 12.8TB, U.2 15mm, Non-OPAL

  • 8 TB capacity stores massive datasets in a single U.2 15 mm drive
  • PCIe 4.0 x4 NVMe interface delivers up to 7100 MB/s sequential read throughput
  • 1,000,000 random read IOPS accelerates latency-sensitive enterprise workloads
  • 144-layer 3D TLC NAND enables 2,000,000-hour MTBF for continuous operation
  • 1000 G shock and 2.17 GRMS vibration ratings protect data in dense server racks

High-capacity enterprise storage

The Solidigm D7-P5620 series drive delivers 12.8TB of capacity in a U.2 15mm form factor. It uses 144L TLC 3D NAND and connects via NVMe over PCI Express 4.0 x4. This SSD targets data-centre operators who need dense, high-throughput storage for cloud compute, eCommerce and database workloads.

Built for continuous operation

The 2.5-inch U.2 15mm package fits standard hot-swap bays and backplanes, allowing replacement without system downtime. With an MTBF of 2,000,000 hours and shock resistance rated at 1,000 G, the drive tolerates the vibration and thermal demands of multi-drive server chassis. No OPAL encryption simplifies deployment in environments that manage security at the array or software layer.

Upgrading from lower-capacity

Moving to this 12.8TB model can reduce the physical storage footprint by up to 50% and lower power consumption by up to 44% compared with multiple smaller drives. Sequential reads reach 7100 MBps and writes 4300 MBps, while random performance hits 1,000,000 read IOPS and 319,000 write IOPS. The jump is worth it when consolidation, QoS consistency above 90% and accelerated database throughput up to 39% outweigh the cost of a single high-capacity module.

Points forts

  • 8 TB capacity stores massive datasets in a single U.2 15 mm drive
  • PCIe 4.0 x4 NVMe interface delivers up to 7100 MB/s sequential read throughput
  • 1,000,000 random read IOPS accelerates latency-sensitive enterprise workloads
  • 144-layer 3D TLC NAND enables 2,000,000-hour MTBF for continuous operation
  • 1000 G shock and 2.17 GRMS vibration ratings protect data in dense server racks

Caractéristiques

BrandSolidigm
SeriesD7-P5620 SERIES
ModelD7-P5620
Part NumberSSDPF2KE128T1N1
Form FactorU.2 15mm
Capacity12.8TB
Memory Components144L TLC 3D NAND
InterfaceNVMe; PCI Express 4.0 x4
Max Sequential ReadUp to 7100 MBps
Max Sequential WriteUp to 4300 MBps
MTBF2,000,000 hours
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Poids d’expédition0.16 kg
Dimensions du colis254 × 127 × 127 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What does the PCIe 4.0 x4 interface cap the sequential throughput at for this drive?

The PCIe 4.0 x4 interface supports up to 7100 MBps sequential read and 4300 MBps sequential write on this SSD.

What physical clearance does the U.2 15mm 2.5 inch form factor need in a server bay?

This 2.5 inch U.2 drive is 15mm thick and requires a bay that accepts 15mm z-height drives.

How is the NVMe drive installed in a hot-swap backplane, and what step is often missed?

Slide the U.2 drive into the hot-swap carrier until the connector seats firmly; the common miss is not engaging the latch fully.
