Green PCB network card with single RJ45 port and low-profile bracket

STARTECH

STARTECH ST1000SPEXI network card

SKU CH-EFHN-PZFN1 MPN ST1000SPEXI

Adds a 10/100/1000 RJ-45 Ethernet port via one PCIe x1 slot using an Intel I210-AT chipset

  • StandardsIEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 10
  • Speed10/100/1000Mbps
  • Connectors1 x RJ-45 Female
  • Interface1 x PCI Express x1 Male
  • LEDs1 x 100/1000 Mbps Indicator 1 x Link / Activity
  • FeaturesAdd Gigabit Ethernet to a client, server or workstation thro
  • Adds a Gigabit Ethernet port through a single PCIe x1 slot
  • Intel I210-AT chipset delivers reliable 10/100/1000 Mbps performance
  • Supports Wake-on-LAN for remote power management
  • 9K jumbo frame support boosts throughput for large transfers
  • Includes low-profile bracket for compact chassis installations

Single-port PCIe Gigabit adapter

The StarTech ST1000SPEXI adds one RJ-45 port to a desktop, server or workstation through a PCI Express x1 slot. An Intel I210-AT chipset drives 10/100/1000 Mbps speeds with full IEEE 802.3 compliance. PXE boot, Wake-on-LAN and 9K jumbo frames are supported out of the box. A low-profile bracket is included for compact chassis.

Suits systems lacking onboard Ethernet

Ideal for restoring wired connectivity after a failed integrated port or adding a dedicated link for virtualisation traffic. The single port limits configurations that need teaming, failover or separate management and data networks. Builds requiring fibre uplinks, multi-gigabit speeds or additional ports should select a different adapter.

Fits any free PCIe x1 slot

Installation consumes one PCI Express x1 lane and a rear bracket opening; the half-height board clears standard low-profile cases. No auxiliary power connector is required. The card frees the motherboard’s integrated controller for other tasks while providing a reliable Intel-based link for imaging, backup or iSCSI workloads.

Points forts

  • Adds a Gigabit Ethernet port through a single PCIe x1 slot
  • Intel I210-AT chipset delivers reliable 10/100/1000 Mbps performance
  • Supports Wake-on-LAN for remote power management
  • 9K jumbo frame support boosts throughput for large transfers
  • Includes low-profile bracket for compact chassis installations

Caractéristiques

BrandStarTech.com
ModelST1000SPEXI
StandardsIEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
IEEE 802.1Q VLAN Tagging
IEEE 802.3x Full Duplex Flow Control
Speed10/100/1000Mbps
Connectors1 x RJ-45 Female
Interface1 x PCI Express x1 Male
LEDs1 x 100/1000 Mbps Indicator
1 x Link / Activity
FeaturesAdd Gigabit Ethernet to a client, server or workstation through a PCI Express slot
Single Port PCIe network adapter card with Intel I210-AT Chipset
PCI Express Gigabit network card / PCI Express Gigabit LAN card / PCI Express Gigabit server adapter / Gigabit Network Card / PCIe Gigabit NIC
Provides fully compliant 10/100/1000 RJ-45 Ethernet port through single PCIe slot
PXE network boot support
Supports Audio-Video Bridging
Wake-on-LAN
Auto MDIX support
9K jumbo frame support
Dimensions0.71" x 4.72" x 2.60"
Weight0.08 lb.
Package Contents1 x 1 Port Network Card
1 x Low Profile Bracket
1 x Instruction Manual
Poids d’expédition0.10 kg
Dimensions du colis170 × 140 × 30 mm

Questions sur cet article

My motherboard has a PCIe x1 slot — is that the only slot this card needs?

Yes, the ST1000SPEXI plugs into a single PCI Express x1 slot and draws power from it; no extra cables or larger slots are required.

Will the Intel I210-AT chipset negotiate 100 Mbps on my old 100BASE-TX switch?

Yes, the card supports IEEE 802.3u 100BASE-TX and autonegotiation, so it will link at 100 Mbps with that switch.

Which LED should be lit to confirm a 1000 Mbps link after I install the card?

The 100/1000 Mbps indicator lights for a gigabit connection, while the Link/Activity LED blinks during traffic.
