Silver 1U rack server front with four 3.5-inch drive trays

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2650 v4 2.2GHz 256GB DDR4 4x 3.5" bays

SKU CH-B5XS-7P7TB

1U rack server with dual 12-core Xeon E5-2650 v4 CPUs at 2.2 GHz, 256 GB DDR4 ECC memory, LSI MegaRAID 9361-8i controller, four 3.5" hot-plug bays, quad 10GBase-T ports, IPMI 2.0.

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores12-Core Processor
  • Dual 12-core Xeon processors at 2.2 GHz with 2.9 GHz turbo for heavy compute
  • 256 GB DDR4 2400 MHz registered ECC memory across 8 DIMM slots
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Four 10GBase-T Ethernet ports via Intel X540 for high-speed networking
  • Redundant 750 W platinum power supplies with hot-swap capability

High-density 1U dual-Xeon server

The Supermicro SYS-6018U-TR4T+ is a 1U rackmount server fitted with two Intel Xeon E5-2650 v4 12-core processors running at 2.2 GHz. It arrives with 256 GB of DDR4 ECC registered memory across eight 32 GB modules and a MegaRAID 9361-8i controller with 1 GB cache. Four hot-plug 3.5-inch drive bays support SATA and SAS drives, while quad 10GBase-T ports and a dedicated IPMI 2.0 interface handle networking and remote management. Dual 750 W platinum power supplies provide redundant hot-swap power.

Suited for virtualization and compute clusters

This system targets environments that need dense multi-threaded performance in a single rack unit, such as virtualization hosts, HPC nodes or private-cloud infrastructure. The 24 DIMM slots and dual-socket design allow memory-heavy workloads to scale within the same chassis. Buyers who require more than four 3.5-inch drive bays or need front bezel and rack rails included should look elsewhere. GPU-dependent workloads are not a fit given the Matrox G200 graphics with 8 MB video memory.

Four 3.5-inch hot-plug bays with SAS/SATA support

The single specification that decides fit is the storage bay count and interface: exactly four 3.5-inch hot-plug bays wired for SATA and SAS drives behind the MegaRAID 9361-8i controller. No 2.5-inch bays or additional drive cages are present in this configuration. Confirm that four large-form-factor bays satisfy the capacity and redundancy plan before purchase.

Points forts

  • Dual 12-core Xeon processors at 2.2 GHz with 2.9 GHz turbo for heavy compute
  • 256 GB DDR4 2400 MHz registered ECC memory across 8 DIMM slots
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Four 10GBase-T Ethernet ports via Intel X540 for high-speed networking
  • Redundant 750 W platinum power supplies with hot-swap capability

Caractéristiques

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores12-Core Processor
# of Processors InstalledE5-2650 V4
Installed Memory Size256GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

What rack-mount depth and rails does the 1U SYS-6018U-TR4T+ chassis require?

The 1U CSE-819U chassis fits a standard 19-inch rack; front bezel and rack-mount rails are not included, so you must supply compatible sliding rails for the cabinet depth you use.

How do I install the dual E5-2650 v4 processors and 256 GB DDR4 memory, and what step is often missed?

Open the top cover, seat each 12-core CPU into its LGA 2011-3 socket, then populate the 24 DIMM slots with registered ECC DDR4 2400 MHz modules; the step often missed is applying fresh thermal paste and torquing the heatsink retention screws in the correct diagonal sequence.

Which components will need replacement or firmware updates during the server's service life?

The MegaRAID 9361-8i controller cache battery, the two 750 W platinum power supplies, the four 3.5-inch drive trays, and the IPMI 2.0 / X540 firmware should all be monitored and replaced or updated as they age.
