1U silver rack server, four front 3.5-inch drive trays, dual Xeon, 32GB DDR4

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2650 v4 32GB DDR4 4x 3.5" bays

SKU CH-V842-CTT36

Dual 12-core Xeon E5-2650 v4 1U server with 32GB DDR4, MegaRAID 9361-8i, four 3.5" hot-plug bays, quad 10GBase-T and IPMI 2.0

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores12-Core Processor
  • Dual Xeon E5-2650 v4 processors deliver 24 cores at 2.2 GHz with 2.9 GHz Turbo
  • 32 GB DDR4 2400 MHz registered ECC memory provides error-correcting capacity for critical workloads
  • MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60 with 1 GB cache and battery backup
  • Four 10GBase-T ports via Intel X540 give high-speed network connectivity for virtualization and storage traffic
  • Dual 750 W Platinum hot-swap power supplies maintain uptime during a supply failure

Dual Xeon 1U server for dense compute

The Supermicro SYS-6018U-TR4T+ is a 1U rackmount server fitted with two Intel Xeon E5-2650 v4 processors, each running at 2.2 GHz with 12 cores. It ships with 32 GB of DDR4 2400 MHz registered ECC memory across four modules. The platform targets virtualization, HPC and cloud workloads that need high core counts in minimal rack space.

Redundant power and quad 10GBase-T

Two 750 W Platinum hot-swap power supplies provide redundancy without shutting down. The MegaRAID 9361-8i controller manages up to eight SAS or SATA drives with 1 GB cache and battery backup, supporting RAID 0, 1, 5, 6, 10, 50 and 60. Four front 3.5-inch hot-plug bays accept SATA or SAS media. A dedicated RJ45 IPMI 2.0 port enables KVM-over-LAN and virtual media, while the Intel X540 add-in card delivers four 10GBase-T RJ45 ports for high-speed networking.

Upgrades from single-socket or 1GbE systems

The dual-socket design doubles thread capacity compared with single-processor 1U units, making the jump worthwhile when licensing or memory bandwidth scales with cores. Quad 10GBase-T replaces single or dual 1 GbE links for storage replication and VM migration. Buyers who need more than four 3.5-inch bays or front bezel and rails included should look elsewhere.

Points forts

  • Dual Xeon E5-2650 v4 processors deliver 24 cores at 2.2 GHz with 2.9 GHz Turbo
  • 32 GB DDR4 2400 MHz registered ECC memory provides error-correcting capacity for critical workloads
  • MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60 with 1 GB cache and battery backup
  • Four 10GBase-T ports via Intel X540 give high-speed network connectivity for virtualization and storage traffic
  • Dual 750 W Platinum hot-swap power supplies maintain uptime during a supply failure

Caractéristiques

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores12-Core Processor
# of Processors InstalledE5-2650 V4
Installed Memory Size32GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

What RAID levels can the MegaRAID 9361-8i controller handle?

The MegaRAID 9361-8i supports RAID 0, 1, 5, 6, 10, 50 and 60 across its eight SAS 12Gb/s ports with 1GB cache and battery backup.

Which drive trays are included and what form factor do they accept?

Four Supermicro 3.5" SAS/SATA hot-plug trays are supplied; the chassis has no 2.5" trays installed despite the broader series supporting them.

How do the dual 750W power supplies connect and what clearance is needed?

Both Platinum-efficiency units are hot-swap redundant and slide into the rear of the 1U chassis; allow standard 1U rack depth for cables and airflow.
