Silver 1U rack server front with four 3.5-inch drive bays and control panel

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2660 v4 14-core 2.0 GHz 16GB DDR4 4x 3.5" bays

SKU CH-94AQ-F5J6T

1U rack server with dual 14-core Xeon 2.0 GHz CPUs, 16 GB DDR4, four 3.5" hot-plug bays, MegaRAID 9361-8i, quad 10GBase-T ports, IPMI 2.0 and redundant 750 W power supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.00 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual 14-core Xeon 2660 v4 CPUs at 2.0 GHz with 3.2 GHz Turbo for multi-threaded throughput
  • 16 GB DDR4 2400 ECC registered memory protects data integrity in critical workloads
  • MegaRAID 9361-8i 12 Gb/s controller with 1 GB cache and battery backs RAID 0/1/5/6/10/50/60
  • Four 3.5-inch hot-plug SATA/SAS bays plus four 10 GbE RJ45 ports on Intel X540
  • IPMI 2.0 dedicated LAN with KVM-over-LAN plus dual 750 W platinum redundant power supplies

Dual Xeon E5-2660 v4 1U rack server

The Supermicro SYS-6018U-TR4T+ is a 1U rackmount server system with two Intel Xeon E5-2660 v4 processors. Each CPU provides 14 cores at 2.0 GHz with a 3.2 GHz turbo frequency. The system ships with 16 GB of DDR4 2400 MHz registered ECC memory installed across 24 DIMM slots. It is built for dense compute tasks in enterprise and data centre racks.

Virtualisation hosts and HPC clusters.

This server suits teams running virtualisation, high-performance computing or cloud workloads that benefit from dual-socket parallelism and quad 10GBase-T networking. The LSI MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50 and 60 across four hot-plug 3.5-inch SATA or SAS drive bays. Buyers who need GPU acceleration or more than four drive bays should look at a different platform.

Four 3.5-inch hot-plug bays with MegaRAID 9361-8i

The single specification that decides fit is the storage layout: four 3.5-inch hot-plug bays backed by an 8-port SAS 12 Gb/s MegaRAID 9361-8i controller with 1 GB cache and battery backup. This combination fixes the maximum drive count and the RAID levels available without adding external enclosures or a different controller.

Points forts

  • Dual 14-core Xeon 2660 v4 CPUs at 2.0 GHz with 3.2 GHz Turbo for multi-threaded throughput
  • 16 GB DDR4 2400 ECC registered memory protects data integrity in critical workloads
  • MegaRAID 9361-8i 12 Gb/s controller with 1 GB cache and battery backs RAID 0/1/5/6/10/50/60
  • Four 3.5-inch hot-plug SATA/SAS bays plus four 10 GbE RJ45 ports on Intel X540
  • IPMI 2.0 dedicated LAN with KVM-over-LAN plus dual 750 W platinum redundant power supplies

Caractéristiques

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.00 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2660 V4
Installed Memory Size16GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

What rack depth and rail kit does the 1U SYS-6018U-TR4T+ require?

The server is a 1U unit that fits a standard 19-inch rack; front bezel and rack-mount rails are not included, so you must supply compatible sliding rails for the chassis depth.

How are the two Xeon E5-2660 v4 processors and the 9361-8i RAID card installed, and what step is often missed?

Both CPUs drop into the LGA 2011-3 sockets on the X10DRU-i+ motherboard and the RAID controller seats in a PCIe slot; the step often missed is connecting the RAID battery backup module to the 9361-8i card.

What components will need replacement first in the SYS-6018U-TR4T+?

The two 750 W Platinum hot-swap power supplies and the RAID controller battery are the primary field-replaceable units; drive trays and fans are also hot-swappable for later maintenance.
