Silver 1U rack server with four front 3.5-inch drive trays, dual power supplies and quad 10GBase-T ports

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2699 v4 2.2GHz 22-core 512GB DDR4 4x 3.5" bays

SKU CH-8HMF-65N13

Dual 22-core Xeons at 2.2 GHz with 512 GB DDR4, 4-bay hot-plug storage, quad 10GbE and IPMI in a 1U chassis

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores22-Core Processor
  • Dual Xeon E5-2699 v4 22-core CPUs provide 2.2 GHz base with 3.6 GHz turbo
  • 512 GB DDR4 2400 MHz ECC registered memory across 16 DIMMs
  • MegaRAID 9361-8i 12 Gb/s SAS controller with 1 GB cache and battery backup
  • Four 3.5" hot-plug SATA/SAS drive bays with included trays
  • Quad 10GBase-T RJ45 ports plus dedicated IPMI 2.0 management LAN

Dual Xeon 1U server for dense compute

The SYS-6018U-TR4T+ fits two E5-2699 v4 processors, each running at 2.2 GHz with 22 cores, into a single rack unit. 512 GB of DDR4 ECC memory across 16 modules supports large virtualisation clusters or in-memory databases. Four hot-plug 3.5-inch bays accept SATA or SAS drives for local storage.

MegaRAID 9361-8i and quad 10GBase-T

The hardware RAID controller provides eight 12 Gb/s SAS ports with 1 GB cache and battery backup, enabling RAID 0, 1, 5, 6, 10, 50 and 60 without consuming CPU cycles. A dedicated add-on card adds four RJ45 ports driven by the Intel X540 controller, giving line-rate 10 GbE connectivity for storage replication or east-west traffic.

IPMI 2.0 and fixed 1U constraints

The dedicated IPMI LAN port offers KVM-over-LAN and virtual media for lights-out management, independent of the operating system. Redundant 750 W platinum power supplies maintain uptime during a unit failure. The 1U chassis limits expansion to low-profile cards and excludes front bezel and rack rails, which must be sourced separately.

Points forts

  • Dual Xeon E5-2699 v4 22-core CPUs provide 2.2 GHz base with 3.6 GHz turbo
  • 512 GB DDR4 2400 MHz ECC registered memory across 16 DIMMs
  • MegaRAID 9361-8i 12 Gb/s SAS controller with 1 GB cache and battery backup
  • Four 3.5" hot-plug SATA/SAS drive bays with included trays
  • Quad 10GBase-T RJ45 ports plus dedicated IPMI 2.0 management LAN

Caractéristiques

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores22-Core Processor
# of Processors InstalledE5-2699 V4
Installed Memory Size512GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

How often will the battery on the MegaRAID 9361-8i controller need replacement?

The controller includes a 1GB cache with battery backup; battery life varies with write workload and ambient temperature, so plan on checking it during routine server maintenance cycles.

What thermal limit appears first when both Xeon E5-2699 v4 processors run at 3.6GHz turbo continuously?

The 1U chassis relies on high-speed fans to cool 45 CPU cores and 512GB of DDR4; sustained turbo loads will hit the thermal envelope of the compact heatsinks before the 750W power supplies reach their limits.

How loud are the fans when the server runs 24/7 with all 24 DIMM slots populated?

Expect elevated fan noise in a 1U form factor; dual 750W platinum supplies and dense memory population keep airflow high, so the system is suited for a dedicated server room rather than an office desk.
