Silver 2U rack server front with twelve 3.5 inch drive bays

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2× Xeon E5-2667 v4 3.2 GHz 16 GB DDR4 12× 3.5″ bays

SKU CH-AZF5-5DCZZ

Dual Xeon E5-2667 v4 2U server with 16 GB DDR4, 12 hot-swap 3.5″ bays, quad 10GBase-T LAN and redundant 1000 W power

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed3.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores8-Core Processor
  • Dual Xeon E5-2667 v4 CPUs deliver 16 cores at 3.2 GHz base
  • 16 GB DDR4 2400 MHz ECC memory supports multi-threaded workloads
  • MegaRAID 9361-8i handles RAID 0, 1, 5, 6, 10, 50, 60 with 1 GB cache
  • 12 hot-swap 3.5″ SAS/SATA bays provide high-density local storage
  • Quad 10GBase-T ports via Intel X540 plus IPMI 2.0 enable fast data and remote management

Dual-socket 2U server for virtualization

This 2U rackmount server ships with two Intel Xeon E5-2667 v4 processors running at 3.2 GHz with eight cores each. It includes 16 GB of DDR4 2400 MHz registered ECC memory across 24 DIMM slots. The system is built for enterprise compute tasks such as virtualization, database management and cloud workloads.

12 hot-swap 3.5″ drive bays

The chassis provides twelve front-accessible 3.5″ bays for SATA or SAS drives. Storage is managed by an LSI MegaRAID 9361-8i controller with 1 GB cache and battery backup supporting RAID 0, 1, 5, 6, 10, 50 and 60. No drives are installed.

Quad 10GBase-T networking

Four RJ45 10GBase-T ports are provided by an Intel X540 controller on a dedicated add-in card. A dedicated RJ45 IPMI 2.0 port enables KVM-over-LAN and virtual media. Dual hot-swap 1000 W titanium-efficiency power supplies deliver redundancy. Front bezel and rack rails are not included.

Points forts

  • Dual Xeon E5-2667 v4 CPUs deliver 16 cores at 3.2 GHz base
  • 16 GB DDR4 2400 MHz ECC memory supports multi-threaded workloads
  • MegaRAID 9361-8i handles RAID 0, 1, 5, 6, 10, 50, 60 with 1 GB cache
  • 12 hot-swap 3.5″ SAS/SATA bays provide high-density local storage
  • Quad 10GBase-T ports via Intel X540 plus IPMI 2.0 enable fast data and remote management

Caractéristiques

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed3.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores8-Core Processor
# of Processors InstalledE5-2667 V4
Installed Memory Size16GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

What does 3.2 GHz on the Xeon E5-2667 v4 mean once the server is running a typical workload?

The 3.2 GHz base clock runs across all eight cores of each installed Xeon E5-2667 v4; Turbo can lift a single core to 3.6 GHz for bursty tasks.

What does the Intel X540 10GBase-T interface cap in practice?

Four RJ45 ports share the X540 controller, each limited to 10 Gb/s over copper cabling.

What mounting hardware is required to install this 2U chassis in a rack?

Front bezel and rack-mount rails are not included; the unit needs standard 2U rail kits to secure it.
