Silver 2U rack server with twelve front 3.5-inch drive trays and dual power supplies

Supermicro

Supermicro SYS-6029U-E1CR4T 2U rack server 2x Xeon Platinum 8160 256GB DDR4 12x 3.5" bays

SKU CH-745Y-VE5GS

Dual Xeon Platinum 8160 2U rack server with 256GB DDR4, 12 hot-swap 3.5" bays, MegaRAID 9361-8i, 4×10GBase-T and IPMI 2.0

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores24-Core Processor
  • Dual 24-core Xeon Platinum 8160 processors at 2.1 GHz handle heavy compute loads
  • 256 GB DDR4-2666 ECC registered memory supports large virtualised workloads
  • 12 hot-swap 3.5″ SAS/SATA drive bays provide high-density local storage
  • MegaRAID 9361-8i with 1 GB cache enables RAID 0, 1, 5, 6, 10, 50, 60
  • Four 10GBase-T ports plus dedicated IPMI 2.0 LAN give fast, managed connectivity

Built for Consolidation Workloads

The Supermicro SYS-6029U-E1CR4T is a 2U rackmount server system delivered new with dual Intel Xeon Platinum 8160 processors at 2.1 GHz, 24 cores each, and 256 GB of DDR4 ECC registered memory. It includes a MegaRAID 9361-8i controller supporting RAID 0, 1, 5, 6, 10, 50, 60 across twelve 3.5-inch hot-swap drive bays. Dual 1000 W titanium power supplies and IPMI 2.0 with dedicated LAN complete the platform.

Fits Virtualisation and Storage Clusters

This server suits teams deploying hyper-converged infrastructure or dense virtualisation hosts who need high core counts, large memory capacity, and four 10GBase-T ports in a 2U form factor. Buyers requiring GPU compute, NVMe boot drives, or front bezel and rails included should look at other configurations.

Twelve 3.5-Inch Hot-Swap Bays Define Capacity

The single specification that decides fit is the twelve 3.5-inch SATA/SAS hot-plug bays backed by the 8-port MegaRAID 9361-8i. If your storage plan needs more than twelve large-form-factor drives or requires NVMe without an additional add-in card, this chassis will not meet the requirement.

Points forts

  • Dual 24-core Xeon Platinum 8160 processors at 2.1 GHz handle heavy compute loads
  • 256 GB DDR4-2666 ECC registered memory supports large virtualised workloads
  • 12 hot-swap 3.5″ SAS/SATA drive bays provide high-density local storage
  • MegaRAID 9361-8i with 1 GB cache enables RAID 0, 1, 5, 6, 10, 50, 60
  • Four 10GBase-T ports plus dedicated IPMI 2.0 LAN give fast, managed connectivity

Caractéristiques

BrandSUPERMICRO
SeriesCSE-829U2E1C4-R1K02-T-X11DPU
ModelSYS-6029U-E1CR4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores24-Core Processor
# of Processors InstalledPlatinum 8160
Installed Memory Size256GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via Intel X710 (AOC-2UR66-i4XTF)
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

What rack height and rail depth does the 2U chassis require?

The server occupies 2U of rack space and uses full-height expansion slots up to 10.5 inches long, so rails must support that depth.

How are the Xeon Platinum 8160 processors seated, and what step is often missed?

Each CPU drops into an LGA 3647 socket; the common mistake is skipping the torque sequence on the retention mechanism, which prevents full contact.

When will the MegaRAID 9361-8i controller battery need replacement?

The 1 GB cache battery typically lasts three to five years; plan to swap it when the controller logs a battery-learn failure or capacity alert.
