Silver 1U rack server with twelve front 3.5-inch drive trays

Supermicro

Supermicro SYS-6029U-E1CR4T rack server 2× Xeon 8160 24-core 2.1 GHz 32 GB DDR4 12× 3.5" bays

SKU CH-F15Q-CCXE3

Dual-socket 2U server with twelve 3.5" hot-swap bays, dual Xeon 8160 24-core CPUs, 32 GB DDR4, MegaRAID 9361-8i and four 10 GbE ports

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores24-Core Processor
  • Dual Xeon Platinum 8160 CPUs provide 24 cores each at 2.1 GHz base
  • 32 GB DDR4-2666 ECC registered memory installed across four modules
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Twelve 3.5-inch hot-swap drive bays accept SAS and SATA drives
  • Four 10GBase-T ports via Intel X710 plus dedicated IPMI 2.0 management LAN

Dual Xeon 24-core 2.1 GHz server

The Supermicro SYS-6029U-E1CR4T is a 2U rack server built around two Intel Xeon Platinum 8160 processors. Each CPU delivers 24 cores at 2.1 GHz with 3.7 GHz turbo. The system ships with 32 GB of DDR4-2666 ECC registered memory and a MegaRAID 9361-8i controller.

12-bay hot-swap storage density

This chassis suits teams that need twelve 3.5-inch SAS or SATA drive bays in a compact rack footprint. The four 10GBase-T ports and dual 1000 W titanium power supplies support virtualization and hyper-converged workloads. Buyers who need NVMe boot drives or GPU acceleration should evaluate other platforms.

MegaRAID 9361-8i with battery-backed cache

The installed RAID controller manages eight SAS 12 Gb/s ports and offers RAID 0, 1, 5, 6, 10, 50 and 60 with 1 GB cache protected by a battery module. This specification determines whether the server can meet your array redundancy and rebuild-time requirements.

Points forts

  • Dual Xeon Platinum 8160 CPUs provide 24 cores each at 2.1 GHz base
  • 32 GB DDR4-2666 ECC registered memory installed across four modules
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Twelve 3.5-inch hot-swap drive bays accept SAS and SATA drives
  • Four 10GBase-T ports via Intel X710 plus dedicated IPMI 2.0 management LAN

Caractéristiques

BrandSUPERMICRO
SeriesCSE-829U2E1C4-R1K02-T-X11DPU
ModelSYS-6029U-E1CR4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores24-Core Processor
# of Processors InstalledPlatinum 8160
Installed Memory Size32GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via Intel X710 (AOC-2UR66-i4XTF)
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

Does the server ship with hard drives, or do I need to buy SAS/SATA drives separately?

The system includes twelve 3.5-inch hot-swap trays but no hard drives; you must supply your own SAS or SATA drives.

The spec lists 32 GB DDR4-2666 in four 8 GB modules — how much more memory can I add?

Twenty-four DIMM slots are available, supporting up to 6 TB of DDR4-2933 ECC registered memory when fully populated.

With dual Xeon Platinum 8160 CPUs at 2.1 GHz, what turbo frequency can I expect under load?

Each processor can reach 3.7 GHz turbo depending on core count, power limits and thermal conditions inside the chassis.
