White rectangular Wi-Fi 6 router with four fixed antennas

TP-Link

TP-Link Archer AX23 AX1800 Wi-Fi 6 wireless router

SKU CH-FQMK-HMMES

Dual-band Wi-Fi 6 router delivers up to 1.8 Gbps with four fixed antennas, four gigabit LAN ports and WPA3 security

  • WiFi GenerationWi-Fi 6
  • Wireless StandardIEEE 802.11a / IEEE 802.11ac / IEEE 802.11b / IEEE 802.11g /
  • SecuritySPI Firewall Access Control IP & MAC Binding Application Lay
  • WPAWPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x)
  • WAN Ports1 x 10/100/1000M
  • LAN Ports4 x 10/100/1000M
  • Smooth 4K streaming with up to 1.8 Gbps Wi-Fi speed
  • Connect more devices simultaneously using OFDMA technology reducing lag
  • Broader Wi-Fi coverage from four fixed high-performance antennas with beamforming
  • Free versatile parental controls including URL blocking and profile management
  • Works with most ISPs and supports IPTV with L2TP and PPTP

AX1800 Wi-Fi 6 Router

The TP-Link Archer AX23 is a dual-band wireless router that delivers combined wireless data rates up to 1.8 Gbps using the Wi-Fi 6 standard. It provides one gigabit WAN port and four gigabit LAN ports for wired connections. Four fixed high-performance antennas support beamforming to extend coverage across the home.

Home Users Needing Basic Wi-Fi 6

This router suits households that want faster 4K streaming and lower lag when multiple devices are connected through OFDMA technology. Buyers who require multi-gigabit WAN or LAN ports for internet plans above 1 Gbps should consider other hardware. Those needing tri-band operation or mesh nodes beyond OneMesh compatibility will also need a different solution.

1.8 Gbps Combined Wireless Throughput

The AX1800 rating represents the maximum aggregate speed across the 2.4 GHz and 5 GHz bands. Real-world throughput depends on client capabilities, channel width, and environmental interference. Matching this figure to the broadband plan and device mix determines whether the router meets performance expectations.

Points forts

  • Smooth 4K streaming with up to 1.8 Gbps Wi-Fi speed
  • Connect more devices simultaneously using OFDMA technology reducing lag
  • Broader Wi-Fi coverage from four fixed high-performance antennas with beamforming
  • Free versatile parental controls including URL blocking and profile management
  • Works with most ISPs and supports IPTV with L2TP and PPTP

Caractéristiques

BrandTP-Link
ModelArcher AX23
WiFi GenerationWi-Fi 6
Wireless StandardIEEE 802.11a / IEEE 802.11ac / IEEE 802.11b / IEEE 802.11g / IEEE 802.11n
SecuritySPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
WPAWPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x)
WAN Ports1 x 10/100/1000M
LAN Ports4 x 10/100/1000M
ButtonsWPS/Wi-Fi Button
Power On/Off Button
LED On/Off Button
Reset Button
Wireless Data RatesAX1800 / Up to 1.8Gbps
Frequency Band2.4 GHz / 5 GHz
Antenna4 x Fixed High-Performance Antennas
Transmitted PowerCE:
<20dBm(2.4 GHz)
<23dBm(5.15 GHz~5.25 GHz)
FCC:
<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz)
Operation ModeAccess Point Mode / Wireless Router Mode
VPN supportOpenVPN
PPTP
Power Supply12 V, 1 A
System RequirementsInternet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
Dimensions10.20" x 5.30" x 1.50"
TemperatureOperating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
HumidityOperating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Package ContentsWi-Fi Router Archer AX23
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide

Questions sur cet article

Does the 10/100/1000M WAN port cap my internet speed at 1 Gbps?

Yes, the single Gigabit WAN port limits the maximum wired internet throughput to 1 Gbps even though the Wi-Fi 6 radio can reach 1.8 Gbps aggregate.

How much space do the four fixed antennas need on a desk or shelf?

The chassis measures 10.20 x 5.30 x 1.50 inches; the non-removable antennas extend upward, so allow extra vertical clearance above the 1.50-inch body height.

What is the correct order to connect the modem and power during first-time setup?

Connect the modem to the WAN port first, then apply the 12 V 1 A power adapter; the Tether app will guide the remaining configuration steps.
