Black metal DVR box with front vents and rear BNC ports

Camius

Camius Trivault 4K Hybrid 12-Channel DVR TRIVAULT4K184R video recorder

SKU CH-WWNC-W7HQY

A 12-channel hybrid recorder that handles 8 analog cameras over coax plus 4 IP cameras, records 4K at up to 30 fps with H.265 compression, and supports up to 10 TB on one internal SATA drive

  • Channel8 Channel
  • Supported Protocols960H, AHD CVI, TVI + IP
  • Network InterfaceRTSP/HTTPS/TCP/UPNP/P2P/DDNS/DNS/IP FILTER
  • Video Input+ 4 Channel Over network
  • Video OutputTriVaul4K184R DVR recorder from Camius features a 4K HDMI Ou
  • Audio Input8 Wired Audio Inputs and 1 Output (RCA)

Channels 8 Channel (No HDD)

  • 8 Channel
  • 8 Channel (No HDD)

取り消し線の付いたバージョンは存在しますが、こちらでは取り扱っていません。

Options No HDD

  • No HDD
  • 4 TB
  • 3 TB

取り消し線の付いたバージョンは存在しますが、こちらでは取り扱っていません。

  • 4K HDMI, VGA and CVBS spot-out outputs let you view live footage on multiple monitors
  • 12-channel hybrid recorder handles 8 analogue cameras plus 4 IP channels for flexible expansion
  • H.265 compression and up to 10 TB internal SATA storage give long recording retention
  • Motion, sound, PIR and intelligent detection triggers capture events without filling drives
  • PC, Mac, web and mobile app access keeps you connected to the system from anywhere

12-Channel Hybrid 4K DVR

The Camius Trivault TRIVAULT4K184R is a hybrid video recorder that supports eight analogue channels over coaxial cable and four IP channels over the network. It records at up to 3840×2160 resolution with H.265 compression and provides 4K HDMI, VGA and CVBS spot-out video outputs. The unit is sold without a hard drive or cameras.

Ideal for mixed analogue and IP installations

This recorder suits installers who want to keep existing CVBS, AHD, CVI or TVI cameras while adding up to four IP cameras for a total of twelve channels. It also fits buyers who need wired audio inputs, alarm I/O and RS-485 for PTZ control. Buyers who require more than twelve total cameras or who need internal storage beyond a single 10 TB SATA drive should consider other options.

Single 10 TB SATA drive limit

The DVR accepts only one internal 3.5-inch or 2.5-inch SATA drive with a maximum capacity of 10 TB. This ceiling determines how many days of 4K footage can be retained before the oldest files are overwritten.

特長

  • 4K HDMI, VGA and CVBS spot-out outputs let you view live footage on multiple monitors
  • 12-channel hybrid recorder handles 8 analogue cameras plus 4 IP channels for flexible expansion
  • H.265 compression and up to 10 TB internal SATA storage give long recording retention
  • Motion, sound, PIR and intelligent detection triggers capture events without filling drives
  • PC, Mac, web and mobile app access keeps you connected to the system from anywhere

仕様

BrandCAMIUS
SeriesTrivault
ModelTRIVAULT4K184R
Channel8 Channel
Supported Protocols960H, AHD CVI, TVI + IP
Network InterfaceRTSP/HTTPS/TCP/UPNP/P2P/DDNS/DNS/IP FILTER
Video Input+ 4 Channel Over network
Video OutputTriVaul4K184R DVR recorder from Camius features a 4K HDMI Output to an HDTV monitor and a VGA output. In addition, the DVR has a CVBS output for a SPOT-OUT additional monitor.
Audio Input8 Wired Audio Inputs and 1 Output (RCA)
Frame Rate1 to 30fps per channel (subject to camera specifications)
Compression FormatH.265
Recording TypePRE-RECORDING, POST-RECORDING, Continuous, SCHEDULE, MANUAL, Event triggered (Motion, Sound, PIR, Intelligent detection)
RemoteSYSTEM ACCESS VMS Software (PC/Mac compatible)/ Web-client (Windows) / iOS & Android smartphone app (Camius View)
Storage InstalledThis DVR is sold without a hard drive; its storage can be expanded up to 10TB (1 Internal SATA) + Add NAS using 'add NetHDD" feature
Power SupplyDC12V / 2A
FeaturesThe latest Hybrid 4K DVR recorder is the perfect upgrade if you still have existing coaxial cables and power sources and even analog cameras of various kinds like CVI, TVI, AHD, or CVBS. In addition, it works with IP cameras too. Audio processing and Intelligent Detection are also supported, in addition to remote app access and management. Camius Security DVR works with 8 (eight) analog and 4 IP security cameras. It allows viewing and recording up to 12 HD (high definition) security cameras in total. The security 8 (eight) channel DVR supports H.264 and H.265 video and G711a audio co
Package ContentsDVR, POWER SUPPLY, HDMI, NETWORK CABLE, INSTALLATION GUDIE

この商品に関する質問

What size and type of internal drive does the TRIVAULT4K184R accept?

It takes one 3.5 inch SATA or 2.5 inch SSD up to 10TB capacity.

Which step is often missed when adding IP cameras to this hybrid DVR?

Disabling an unused analog BNC channel to free 8Mbps bandwidth per channel, up to 96Mbps total.

When will the internal hard drive need replacement in this recorder?

Plan to replace the SATA drive once it reaches the 10TB limit or after several years of continuous 24/7 recording.
