Green PCB add-in card with three USB-C and two USB-A ports on a metal bracket

ESTONE

ESTONE PCIE22A3C3.2 PCIe USB 3.2 5-Port 3C2A 10Gbps

SKU CH-VM86-EC70J

Adds five USB 3.2 ports — three Type-C and two Type-A — at up to 10 Gbps through a single PCI Express slot

  • TypePCI to USB Card
  • External USB Ports5x USB Ports
  • StandardUSB 3.2
  • Data Transfer RateUp to 10 Gbps
  • Operating Systems SupportedWindows 7/8/10/11
  • CompatibilityWidely Compatibility: The card is compatible with Windows 7/
  • Adds five USB 3.2 ports via one PCIe x1 slot
  • Three USB-C and two USB-A connectors for mixed devices
  • Up to 10 Gbps transfer rate for fast file moves
  • Powered from the PCIe slot with no extra cable needed
  • Works with Windows 7 through 11 and Mac OS 10.8.2+

Five USB 3.2 ports via PCIe x1

The ESTONE PCIE22A3C3.2 adds three USB-C and two USB-A ports to a desktop through a single PCI Express x1 lane. It targets users who need more high-speed data connections for drives, peripherals or VR headsets without occupying rear motherboard headers. The card draws power directly from the slot and requires no external cable.

Fits any PCIe 2.0 or 3.0 x1, x4, x8 or x16 slot

Installation uses a standard low-profile bracket and the supplied screws. Driver installation is needed for Windows 7, 8 and 10 32/64-bit; Windows 11 and Mac OS 10.8.2 or later typically work without extra software. Each port delivers up to 5 V at 1 A for bus-powered devices.

Independent over-current protection per port

Under sustained multi-device transfers the onboard protection isolates faults without shutting down the whole card. Real-world throughput stays at the connected device's limit, while the 10 Gbps link remains stable during long copy sessions or continuous camera capture.

特長

  • Adds five USB 3.2 ports via one PCIe x1 slot
  • Three USB-C and two USB-A connectors for mixed devices
  • Up to 10 Gbps transfer rate for fast file moves
  • Powered from the PCIe slot with no extra cable needed
  • Works with Windows 7 through 11 and Mac OS 10.8.2+

仕様

BrandESTONE
SeriesPCIE22A3C3.2
ModelPCIE22A3C3.2
TypePCI to USB Card
External USB Ports5x USB Ports
StandardUSB 3.2
Data Transfer RateUp to 10 Gbps
Operating Systems SupportedWindows 7/8/10/11
CompatibilityWidely Compatibility: The card is compatible with Windows 7/8/10/11 (32/64 bit) and Mac OS 10.8.2 and above. The card only requires installing a driver which you can download from our CD driver, when operating on Windows 7. Note: Windows XP,/Vista/7, Server,requires driver installation, Windows 10/11 and Mac OS and Linux don't need drivers.
Specifications5 Ports PCI-E to USB 3.2 HUB PCI Express Expansion Card Adapter 10Gbps for Motherboard
You need to install the RENESAS/VLI USB3.2 driver for your computer first.
Supports PCI Express 3.0 2.0 X1 lane, can transferring up to 10Gbps.
PCI Express x1 slot card for usb expansion 7 Ports USB interface Card (3X USB-C - 2X USB-A)
Power Input: no need extral Power Connector
Power output: +/-5V / 900mA (each port)
Compatible: USB1.1/2.0/3.0/3.2
Operating Systems: Windows7/8/10(32/64bit)
?
FeaturesMaximum extension,Most USB interfaces: Update your Computer to 5 ports USB3.2--3 Port Type C and 2 ports Type A, You can connect keyboard, mouse, external hard drives, CD/DVD drives, webcams,usb printers, scanners, game controllers,USB VR, digital cameras, etc
Increasing Efficiency: Supports transfer rates of up to 10Gbps copying HD videos, music, photos,data files between USB devices and the computer at blazing fast speeds.Note:The actual transmission speed is limited by the setting of the device connected
Widely compatibility: USB 3.2 Backwards compatible with USB 3.0, 2.0 and 1.1
Weight3.2 ounces
Package Contents1x USB 3.2 PCI-E expansion card, 1x CD driver, 1 x installation screws, and 1x user manual.

この商品に関する質問

Will the PCIe x1 lane saturate before the five ports hit 10 Gbps each?

The card uses a single PCIe lane at 3.0 or 2.0 speed, so combined throughput is limited to that lane's bandwidth rather than 10 Gbps per port.

Does the card need extra power or cooling when all ports run at 5 V/1 A continuously?

It draws power from the PCIe slot only, each port is capped at 5 W with per-port over-current protection, and no external power connector or fan is required.

Must the motherboard have a PCI Express x4, x8 or x16 slot for this card to work?

The card fits any PCIe x1, x4, x8 or x16 slot running at 3.0 or 2.0 and works with Windows 7 through 11 and Mac OS 10.8.2 or later.
